ADSL Compliance

• ANSI T1.413 Issue 2
• ITU G.992.1 G.dmt
• ITU G.992.2 G.lite
• ITU G.994.1 G.hs
• ITU ADSL2 G.992.3, G.992.4
• ITU ADSL2+ G.992.5
• Reach-Extended ADSL (RE ADSL)

ATM Support

• 8 PVCs Support
• ATM Forum UNI 3.1/ 4.0
• RFC 1483/2684 Multiple Protocol over AAL5
• RFC 2364 PPP over AAL5
• RFC 2516 PPP over Ethernet
• VC and LLC Multiplexing ATM QoS UBR,CBR,VBR
• I.610 OAM F4/F5 Loop-back, AIS, and RDI OAM Cells

Firewall Security

• Stateful Packet Inspection
• Prevent DoS, DDoS Attack
• Policy-based Access
• Control Content Filtering
• IP & Generic Packet
• Filtering Real-time Attack Alert and Logs

Routing Support

• IEEE 802.1d Transparent Bridging
• IP Routing: TCP, UDP, ICMP, ARP
• RIPv1 and RIPv2
• IP Multicast IGMP v1/v2
• IP Policy Route

IP Management

• SUA/Multi-NAT Internet Sharing
• Multimedia Support
• VPN (IPSec, PPTP) Pass-through
• DHCP Server/Relay/Client
• DNS Proxy
• Dynamic DNS
• UPnP Support

Network Management

• Web-based Configuration
• Telnet Remote Management
• FTP/TFTP for Firmware Upgrade and Romfile Backup and Restore
• SNMP Support
• Built-in Diagnostic Tool

Advanced Features

• Zero Configuration
• Traffic Redirect
• Triple Play Media
• Bandwidth Management (MBM)
• Multimedia Auto Provisioner (MAP)

Hardware Specifications

• ADSL: One RJ-11 or RJ-45 Port
• LAN: 4-port Sw
• itch, 10/100M Auto MDI/MDIX
• Reset Button
• Status LEDs Indicator
• Power 12V AC 1A

Physical Specifications

• Dimensions: 180(W) x 127(D) x 36(H) mm
• Weight: 275 g

Environmental Specifications

Operating Environment:

• OperatingTemperature: 0°C ~ 40°C
• Operating Humidity: 20% ~ 85% (non-condensing)

Storage Environment:

• Storage Temperature: -20°C ~ 60°C
• Storage Humidity: 20% ~ 90% (non-condensing)

Certification

• FCC
• CE
