• 4 x 10/100/1000Mbps Auto-MDIX LAN ports
• 1 x 10/100/1000Mbps WAN port (Internet)
• Wi-Fi Protected Setup (WPS) button
• On/off power switch (EU Version)
• On/off wireless radio button
• LED status indicators
• Compliant with IEEE 802.11n/b/g/a standards
• High-speed data rates of up to 450 Mbps using both 2.4 GHz and 5 GHz bands
• Compatible with most popular cable/DSL Internet Service Providers using Dynamic/Static IP, PPPoE, L2TP, and PPTP connection
• Advanced firewall protection with Network Address Translation (NAT) support
• Advanced wireless security of up to WPA2-RADIUS
• DMZ support
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization
• Support for up to four virtual wireless networks (SSIDs) per wireless band
• Gaming Port Controls: supports opening multiple ports or a range of ports
• Internet Access Control with MAC, URL, Service Type, and IP Range filtering
  • Internet Access Control Rule Scheduling: schedule access to websites, online video games, Internet cameras and more for specific times through the week
• One touch wireless connection to wireless clients using the WPS button
• Easy setup via Web browser using the latest versions of Internet Explorer, FireFox, Safari, and Chrome
• Virtual server and Application Level Gateway (ALG) services for special Internet applications
• Universal Plug and Play (UPnP) for auto discovery and support for device configuration of Internet applications

Artykuły prasowe:

• Test TEW-692GR w Chip.pl
• TEW-692GR - Przegląd routerów w pcfoster.pl
• TEst TEW-692GR w hotfix.pl

• Standards:
  • Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3ab (1000Base-T) , 802.3az
  • Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 802.11a
• LAN: 4 x 10/100/1000Mbps Auto-MDIX port
• WAN: 1 x 10/100/1000Mbps Auto-MDIX port
• WPS Button: Wi-Fi Protected Setup (WPS) connects with other WPS compliant devices
• LED Indicator: Power, LAN 1-4, WAN, 2.4GHz Wireless, 5Ghz Wireless, WPS
• Power Adapter: 12V DC, 1A external power adapter
• Power Consumption: 9.6 watts (max)
• Dimension: 163 x 156 x 26 mm
• Weight: 175g
• Temperature:
  • Operation: 0°~ 40°C
  • Storage: -20°~ 60°C
• Humidity: Max. 90% (non-condensing)
• Certifications: CE, FCC
• Frequency:
  • FCC: 2.412~2.462 GHz, 5.180~5.240 GHz, 5.725~5.850 GHz
  • ETSI: 2.412~2.472 GHz, 5.150~5.250 GHz
• Antenna:
  • 2.4GHz: 3 x 2dBi (internal)
  • 5GHz: 3 x 3dBi (external fixed)
• Modulation:
  • OFDM: BPSK, QPSK, 16-QAM, 64-QAM
  • DBPSK, DQPSK, CCK
• Data Rate:
  • 802.11a: up to 54Mbps
  • 802.11b: up to 11Mbps
  • 802.11g: up to 54Mbps
  • 802.11n: up to 450Mbps (for both 2.4 & 5GHz)
• Security: 64/128-bit WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
• Output Power:
  • 802.11a: 14dBm (typical)
  • 802.11b: 18dBm (typical)
  • 802.11g: 15dBm (typical)
  • 802.11n: 15dBm +/- 1 dBm (typical) (for 2.4 & 5GHz)
• Receiving Sensitivity:
  • 802.11a: -70dBm (typical) @ 54Mbps
  • 802.11b: -84dBm (typical) @ 11Mpbs
  • 802.11g: -72dBm (typical) @ 54Mbps
  • 802.11n: -66dBm +/- 1 dBm (typical) @ 450Mbps (for 2.4 & 5GHz)
• Channels:
  • 2.4GHz: 1~11 (FCC), 1~13 (ETSI)
  • 5GHz: 36, 40, 44, 48, 149, 153, 157, 161 and 165(FCC)
  • 36, 40, 44, and 48 (ETSI)
