Features and Specifications

• Supports PCMCIA-ATA disk interface
• Two 16 bit (PCMCIA 2.1/JEIDA 4.2) PC Card sockets
• Complies with PCI Local Bus Specification 2.1 and greater
• Complies with PCMCIA PC Card 95 Standard Specification
• Patented hardware and software design requires only one PCI slot for IRQs
• 3.3V, 5V, or mixed 3.3/5V PC Card operations
• Automatic detection 16 bit PC Card
• ACPI support

Warranty Information

• 1 Year Limited Warranty

Hardware Requirements

• PC Compatible Computer
• Free PCI Expansion Slot
• Free 3.5" Drive Bay

Operating Systems

• The Windows Vista
• Windows 95, 98, 98SE, Millennium Edition and Windows 2000/XP
• Windows NT 4.0+SP6 (SystemSoft CardWizard 5.2+ recommended)
• Unsupported, but known to work with many Linux and BSD distributions

Package Includes

• PCI Card to two slot PC Card 3.5" Drive Bay device (internal model)
• Drivers on floppy disk
• User guide documentation

PC Card Interface

• Slot 1: up to Type III card
• Slot 2: up to Type II card

Physical Characteristics

• PCI interface card: 155 X 93mm (LW)
• PCI-to-PCMCIA host bridge: PCI-1420

Electrical Characteristics

• 12V @ 3µA typical
• 5V @ 21mA typical
• 3.3V @ 0mA supplied from regulator on 5V rail

Operating Environment

• Operating temperature: 0° C to 60° C
• Storage temperature: -20° C to 80° C
• Relative Humidity: 0% to 90% non-condensin
  g
