Specifications:
|
|
Standards
|
IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.1Q
|
|
Ports
|
Twenty-four 10/100/1000 RJ-45 ports and 2 shared Mini-GBIC slots
|
|
Cabling type
|
Category 5 Ethernet or better
|
|
LEDs
|
System, Link/Activity, Gigabit
|
|
Performance
|
|
Switching capacity
|
48 Gbps, nonblocking
|
|
MAC table size
|
8000
|
|
Number of VLANs
|
256 - static
|
|
Management
|
|
Web user interface
|
Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)
|
|
SNMP
|
SNMP versions 1, 2, and 3 with support for traps
|
|
SNMP MIBs
|
RFC1213 MIB-2, RFC2863 interface MIB, RFC2665 Ether-like MIB, RFC1493 bridge MIB, RFC2674 extended bridge MIB (P-bridge, Q-bridge), RFC2819 RMON MIB (groups 1,2,3,9 only), RFC2737 entity MIB, RFC 2618 RADIUS client MIB
|
|
RMON
|
Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis.
|
|
Firmware upgrade
|
Web browser upgrade (HTTP)
|
|
Trivial File Transfer Protocol (TFTP) upgrade
|
|
Port mirroring
|
Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe
|
|
Other management
|
RFC854 Telnet (menu-driven configuration)
|
|
SSH and Telnet management
|
|
Telnet client
|
|
SSL security for web user interface
|
|
Switch audit log
|
|
Dynamic Host Configuration Protocol (DHCP) client
|
|
BOOTP
|
|
Simple Network Time Protocol (SNTP)
|
|
Xmodem upgrade
|
|
Cable diagnostics
|
|
Ping
|
|
Traceroute
|
|
Security Features
|
|
IEEE 802.1X
|
802.1X - RADIUS authentication; MD5 encryption
|
|
Access control lists (ACLs)
|
Differentiated services code point (DSCP)/IP precedence-based class of service (CoS)
|
|
IPv6 traffic-class-based CoS
|
|
IP address
|
|
Subnet mask
|
|
Protocol
|
|
Service type
|
|
MAC address
|
|
VLAN ID
|
|
TCP/ User Datagram Protocol (UDP) port
|
|
Availability
|
|
Link aggregation
|
Link aggregation using IEEE 802.3ad LACP
|
|
Up to 8 ports in up to 8 trunks
|
|
Storm control
|
Broadcast, multicast, and unknown unicast
|
|
Spanning Tree
|
IEEE 802.1d Spanning Tree, IEEEE 802.1s Multiple Spanning Tree, IEEE 802.1w Rapid Spanning Tree, Fast Linkover
|
|
IGMP snooping
|
IGMP (versions 1 and 2) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors.
|
|
QoS
|
|
Priority levels
|
4 hardware queues
|
|
Scheduling
|
Priority queuing and weighted round-robin (WRR)
|
|
Class of service
|
Port based
|
|
802.1p VLAN priority based
|
|
IP ToS/differentiated services code point (DSCP) based
|
|
IPv4 and IPv6 traffic class based
|
|
Rate limiting
|
Ingress policer, egress shaper
|
|
Layer 2
|
|
VLAN
|
Port-based and 802.1Q-based VLANs
|
|
PVE
|
|
Management VLAN
|
|
Head-of-line (HOL) blocking
|
HOL blocking prevention
|
|
Jumbo frame
|
Supports frames up to 10 KB
|
|
Dynamic VLAN
|
GVRP - dynamic VLAN registration
|
|
Standards
|
802.3i 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet, 802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet, 802.3x flow control
|
|
Environmental
|
|
Dimensions
|
16.93 x 1.75 x 13.78
|
|
W x H x D
|
(430mm x 44.5mm x 350mm)
|
|
Unit weight
|
7.54 lbs (3.42kg)
|
|
Power
|
100-240V, 50-60Hz, internal, universal
|
|
Certification
|
FCC Part 15 Class A, CE Class A, UL, cUL, CE mark, CB
|
|
Operating temperature
|
0 to 40C (32 to 104F)
|
|
Storage temperature
|
-20 to 70C (-4 to 158F)
|
|
Operating humidity
|
10% to 90%
|
|
Storage humidity
|
10% to 95%
|
