| CPU |
Marvell 88F6707 1.0GHz SOC |
| HDD |
2 x 3.5" HDD or 2x 2.5" HDD/SSD |
| Lockable HDD Tray |
Yes |
| OS |
Embedded Linux |
| Largest single HDD capacity supported |
> 4TB |
| DRAM |
512MB DDR3 |
| NAND |
1Gb |
| USB 2.0 |
1 (flash drive, external HDD, hub, printer, digital camera, etc.) |
| USB 3.0 |
2 (front panel) (flash drive, external HDD, hub, printer, digital camera, etc.) |
| Card Reader |
1 (front panel) SD Card |
| 10/100/1000 Ethernet |
1 (100 green, 1000 amber; access/link blinking green)
IEEE 802.3az for Green Lan |
| RAID |
0, 1, JBOD |
| Support single HDD |
Yes and single expansion |
| Hot Swap |
Yes
|
| Hot Swap button (zero configuration) |
1 for each HDD |
| RTC |
Yes
|
| Power Adaptor |
65W |
| Power Consumption (Standby/Operational) |
9.6W / 19W |
| Performance (Read/Write) MB/s |
100/70 MB/s*
*Performance depends on the testing environment |
| Max. # of users |
256 |
| Max. # of share folders |
256 |
| Max. # of concurrent connections |
256 |
| LED Indicators |
Status/power button - dual color (blue/red, access/error),
HDD1 - dual color (blue/red, access/error) HDD2 - dual color (access/error),
USB - single blue color (access), Card reader - single blue color (access) |
| Alarm Buzzer |
System Warning |
| Fan |
Smart fan |
| Reset Button |
Back panel |
| Power Button |
Front panel |
| Secure lock |
Kensington lock |
| Operation Temperature |
0 - 40 ˚C |
| Certification |
CE, FCC, C-TICK, BSMI, CB, EUP Lot6 |
| Chassis |
Aluminum/Plastic |
| Size |
169.8mm (H) x 90.0mm (W) x 225.0mm(L) |
| Weight |
1930 g |
| Accessories |
Power Adaptor (65W), AC Power Cord, Ethernet Cable, CD, QSG, HDD Screws |
| Supported OS |
Microsoft Windows XP and above, Mac OS and Linux |
| Mobile Device Access |
iPhone, iPAD, Android phone, Android tablet |
| Supported Mobile OS |
iOS 6.0 and above, Android 2.3 and above |
| Mobile Device Application |
App Store for iPhone & iPAD, Google Play for Android phone & tablet |
| Supported Browser |
IE 8.0 or later, Firefox 3 or later, Safari 3 or 4 and Google Chrome |
| Languages |
12 (English, 繁體中文, 简体中文, 日本語, Deutsch, Français, Русский, Nederlands, Español, Italiano, Dansk,Türkçe) |
| File System |
Internal : XFS
External: EXT2, EXT3, EXT4, XFS, NTFS, FAT, FAT32 |
| LAN Configuration |
DHCP/Static IP
Auto IP
Hostname/Group name |
| Networking Services |
Samba Server (File sharing)
DHCP client
USB Storage devices sharing
Printer Server
iTunes Server
Twonky DLNA Media Server
Apple File Protocol (AFP)
NTP for time synchronization
FTP/SSL FTP Server |
| Backup |
Quick Copy for USB Storage devices (USB Storages to NAS)
Acronis Backup Software
Time Machine support
NAS to USB Storage backup
NAS to NAS backup
Memory card to NAS |
| Scheduling |
Schedule backup
Schedule for NTP time synchronization |
| Remote Access |
Remote Access by Internet Browser
Remote Access by Smartphone / Tablet
Wake on Lan |
| Disk Management |
HDD Spin-down timer
Single disk, Single disk expansion, RAID 0, RAID 1, JBOD
Check Disk
Disk usage status management
Disk Format
SMART information report |
| Download |
BT Download without PC
(schedule download, tasks download, download configuration, etc.) |
| System Setup/Tools |
On line Firmware upgrade
Time-Zone Settings
Wizard and installer for easy setup
NAS Discovery tool (Finder to search/connect/map drives)
Factory Reset
System log
Schedule on/off
Power interrupt auto resume
One touch on power button to turn on/off LED |
