Interfaces

• LAN: 10/100Base-T (RJ45) MDI/MDI-x autosensing 4-port Ethernet switch
• WAN: ADSL line (RJ11) for ADSL/POTS or ADSL/ISDN

Dimensions

• 33 x 153 x 180 mm (1.30 x 6.02 x 7.09 in.)

Environmental

• Temperature: 0°to 40°C (32 to 105 F)
• Humidity: 20% to 80%
• AC voltage: 100 to 120, 220 to 240 V
• Frequency: 50/60 Hz

Multi-user Router

• ATM-Extensive multi PVC
  - ATM Quality of Service (UBR, CBR, VBR-rt, VBR-nrt)
  - DSLForum TR-37 autoconfi guration
• Bridging-self learning bridge at wire speed
• IP Routing
  - UPnP* certifi ed Internet Gateway Device, enabling major conferencing and gaming technlolgies
  - IPsec passthrough from multiple LAN clients, enabling secure homeworking
  - Supports PPPoE, PPPoA, IPoA, CIP, ETHoA-DNS server and relay, DHCP server and relay
  - Network Address Translation for connection sharing, including support for SIP, H.323, Realaudio, FTP, irc, IKE, IPSec-ESP, Jabber, ILS,...
  - Simultaneous bridging and routing of PPPoE connections, enabling network based VPN’s

* UPnPTM is a certifi cation mark of the UPnPTM Implementers Corporation

Management

• OS independent
• Easy set-up wizard
• Advanced Management via telnet, HTTP, SNMP, event log
• Integrated firewall
• Easy SW upgrade wizard
