PIC16F84, PIC16F84A, PIC16LF84A do 10Mhz MICROCHIP

14-09-2014, 22:08
Aukcja w czasie sprawdzania była zakończona.

Cena kup teraz: 4.50 zł

Użytkownik IC_Parts

numer aukcji: 4578374706

Miejscowość Oświęcim

Koniec: 14-09-2014 21:56:40

High Performance RISC CPU Features:
• Only 35 single word instructions to learn
• All instructions single-cycle except forefekt02program branches which are two-cycle
• Operating speed: DC - 10 MHz clock input DC - 200 ns instruction cycle
• 1024 words of program memory
• 68 bytes of Data RAM
• 64 bytes of Data EEPROM
• 14-bit wide instruction words
• 8-bit wide data bytes
• 15 Special Function Hardware registers
• Eight-level deep hardware stack
• Direct, indirect and relative addressing modes

• Four interrupt sources:
- External RB0/INT pin
- TMR0 timer overflow
- PORTB<7:4> interrupt-on-change
- Data EEPROM write complete

Peripheral Features:
• 13 I/O pins with individual direction control
• High current sink/source for direct LED drive
- 25 mA sink max. per pin
- 25 mA source max. per pin
• TMR0: 8-bit timer/counter with 8-bit programmable prescaler

Special Microcontroller Features:
• 10,000 erase/write cycles Enhanced FLASH Program memoryIC_Partstypical
• 10,000,000 typical erase/write cycles EEPROM Data memory typical
• EEPROM Data Retention > 40 years
• In-Circuit Serial Programming™ (ICSP™) - via two pins
• Power-on Reset (POR), Power-up Timer (PWRT), Oscillator Start-up Timer (OST)
• Watchdog Timer (WDT) with its own On-Chip RC Oscillator for reliable operation
• Code protection
• Power saving SLEEP mode
• Selectable oscillator options

CMOS Enhanced FLASH/EEPROM Technology:
• Low power, high speed technology
• Fully static design
• Wide operating voltage range:
- Commercial: 2.0V to 5.5V
- Industrial: 2.0V to 5.5V
• Low power consumption:
- < 2 mA typical @ 5V, 4 MHz
- 15 mA typical @ 2V, 32 kHz
- < 0.5 mA typical standby current @ 2V

Obudowa DIP18

Wersja niskonapieciowa (2.0-5.5V) PIC16LF84A-04 (kwarc do 10Mhz!)

Uklad PIC16LF84A jest funkcjonalnym odpowiednikiem
PIC16F84, PIC16LF84, PIC16F84A,IC_Parts PIC16LF84A o lepszych parametrach i moze
byc stosowany za nie zamiennie - szczegoly w nocie katalogowej i migracyjnej.

Uklady nowe i nieuzywane.
Cena za 1szt.

PIC16F84A Datasheet
PIC16F84 to PIC16F84A Migration

Posiadam na zyczenie wieksza ilosc tych ukladow
prosze o potwierdzenie przed zakupem

Zapraszam na inne moje aukcje, na ktorych znajduja sie elementy przydatne w systemach uC.

Dodano 2[zasłonięte]008-06 13:35
Ponadto dostepne sa w wiekszych ilosciach:
ADS1110, ADS1112, ADS7822, ADS7828, BUF634, DAC7571, DAC8574, DIR9001, DIT4192, DRV134, INA134, INA139, INA217, ISO7221 C, IVC102, LM2575, LP2951, LP2951, MC34063 A, OPA1602, OPA1612, OPA1632, OPA177, OPA2107, OPA2132, OPA2241, OPA2277, OPA2353, OPA2365, OPA241, OPA340, OPA4134 A, OPA445 A, OPA453, OPA454, OPA552, OPA602 B, OPA633, OPA827, PCA9554 A, PCF8574 A, PCF8575, PCM1748, PCM1792 A, PCM1794 A, PCM1795, PCM1796, PCM1798, PCM1804, PCM2704, PCM2705, PCM2707, PCM2900 B, PCM2902 B, PCM2903, PCM2906 B, PGA2310, PGA2311 A, PGA4311 A, PLL1708, REG102, REG113, SN65LV1023 A, SN65LV1224 B, SN75LV4737, SRC4192, SRC4392, TAS1020 B, TAS3108, TAS5162, TAS5261, TAS5504 A, TAS5508 B, TAS5518, THS3061, THS3120, THS4130, THS4131, THS6012, TIR1000, TL431, TL783, TLC1549, TLC272, TLC549, TLE2072, TLE2082, TLE2142, TLE2426, TLV1117 -50, TLV1544, TMP411, TPA1517, TPA152, TPA6111 A2, TPA6120 A2, TPIC6A595, TPS2051 B, TPS60403, TPS71733, TPS71750, TPS7201, TPS7333, TPS76038, TPS79333, TPS79633, TPS79650, UC2577 -ADJ, UC3525, UC3611, UC3845 A, UC3909, UCC283 -ADJ, UCC37321, UCC37322, ULN2803, LME49713, LME49722, LME49725, LME49810, LME49830,
LME49600, LME49720, LME49710, LME49990, stoliki 2xSOIC-DIP i SOIC-DIP z opcja wlutowania
