CPU

• Supports Socket 478 for Intel® Pentium 4/Celeron processor
• Supports 1.4 ~ 3.06GHz and up

Chipset

• Intel® 845GE Chipset
 - Integrated 2D/3D graphic controller
 - Support PC2700 (DDR333) technology
 - Supports 100/133MHz FSB
 - Supports 400/533MHz Intel NetBurst micro-architecture bus

• Intel® ICH4 Chipset
 - AC'97 2.2 interface
 - 6 USB 2.0/1.1 ports
 - 2 channel Ultra ATA/100 Bus Master IDE controller
 - SMBus 2.0 support
 - Integrated LAN controller

FSB

• Support 100/133MHz FSB
• Support 400/533MHz Intel NetBurst micro-architecture bus.

Main Memory

• Supports two 184-pin DDR200/DDR266/DDR333 DIMMs
• Supports Max. memory size of 2GB
• Support 2.5V DDR DIMM
• No support ECC Function
  Note: FSB533 CPU is required in order to choose DDR333 selection in the BIOS setup.

Slots

• One AGP (Accelerated Graphics Port) 4x slot
• Three PCI 2.2 32-bit Master bus slots (support 3.3v/5v)
• One CNR (Communication Network Riser) slot

On-Board IDE

• An IDE controller integrated in ICH4
• Support PIO, Bus Master and Ultra ATA66/100 operation modes
• Can connect up to four IDE devices

Video

• Integrated Intel Extreme Graphics

Audio

• 6 channels S/W audio codec Realtek ALC650
- Compliance w/AC97 v2.1 spec
- Meet PC2001 audio performance requirement

Network (Optional, 845GEM-L only)

• PCI local bus single-chip Fast Ethernet Controller
• RealTek RTL8101L with external Base-T lan transformer
 - Integrated Fast Ethernet MAC and PHY in one chip.
 - Supports 10Mb/s and 100Mb/s auto-negotiation operation.
 - Compliance with PCI v2.2.
 - Compliance with PC99 and PC2001 standard.
 - Supports Wake-On-LAN and remote wake-up.
 - Supports ACPI power management.

Modem (Optional, 845GEM-L only)

• Supports MSI proprietary modem card MS-6961

On-Board Peripherals

On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial ports (COM A)
- 1 VGA port
- 1 parallel port
- 1 RJ-45 LAN jack(optional)
- 1 audio/game port
- 2 USB ports

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and
  expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your
  motherboard specifications.

Dimension

• 24.5 cm(L) x 21.4 cm(W) ATX Form Factor
