Płyta MSI 865-Neo2 - swego czasu bardzo ceniona, razem z procesorem i wentylatorem. Nie chce już demontować zestawu, był tam chyba PIV 2600 albo 2800MHz - na pewno jeden z ostatnich modeli.

CPU
􀁨 Supports Intel® P4 Northwood/Prescott (Socket 478) processors.
􀁨 FSB 400 (for Northwood only), 533, 800MHz.
􀁨 Supports up to 3.2GHz or higher speed.
Chipset
􀁨 Intel® 865PE/G chipset
- Supports FSB 800/533/400MHz.
- Supports AGP 8X interface.
- Supports DDR 400/333/266 memory interface.
- Integrated graphics controller (for 865G only).
􀁨 Intel® ICH5/ICH5R chipset
- Hi-Speed USB (USB2.0) controller, 480Mb/sec, 8 ports.
- 2 Serial ATA/150 ports.
- 2 channel Ultra ATA 100 bus Master IDE controller.
- PCI Master v2.3, I/O APIC.
- Supports both ACPI and legacy APM power management.
- Serial ATA/150 RAID 0 and RAID 1 (Optional).
Main Memory
􀁨 Supports four unbuffered DIMM of 2.5 Volt DDR SDRAM.
􀁨􀁨􀁨􀁨􀁨 Supports up to 4GB memory size without ECC.
􀁨􀁨􀁨􀁨􀁨 Supports Dual channel DDR266/333/400/433/466/500/533 MHz and up.
(DDR433/466/500/533 are overclocking spec)
Slots
􀁨 One AGP slot supports 8x/4x at 0.8V (AGP 3.0) or 4x at 1.5V (3.3V is not
supported).
􀁨 Five 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface).
On-Board IDE
􀁨 Dual Ultra DMA 66/100 IDE controllers integrated in ICH5/ICH5R.
- Supports PIO, Bus Master operation modes.
- Can connect up to four Ultra ATA drives.
􀁨 Serial ATA/150 controller integrated in ICH5/ICH5R.
- Up to 150MB/sec transfer speeds.
- Can connect up to two Serial ATA drives.
- Supports SATA RAID 0/RAID 1 (Optional).

VIA6420 On-Board (Optional)
􀁨􀁨􀁨􀁨􀁨 Supports Ultra ATA, Serial ATA, Serial ATA RAID 0 or 1.
􀁨􀁨􀁨􀁨􀁨 Connect up to 2 Serial ATA devices and 2 Ultra ATA 133 devices.
On-Board Peripherals
􀁨 On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 1 serial port COM1, 1 VGA port (for 865G only) (Optional)
- 1 parallel port supports SPP/EPP/ECP mode
- 8 USB 2.0 ports (Rear * 4/ Front * 4)
- 1 Line-In / Line-Out / Mic-In / Real Speaker Out / Center-Subwoofer Speaker
Out / SPDIF Out-Optical audio port (Optional)
- 1 RJ45 LAN jack (Optional)
- 2 IEEE 1394 pinheaders (Optional)
Audio
􀁨 AC97 link controller integrated in Intel® 865PE/G chipset.
􀁨 6-channel audio codec Realtek ALC655.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.
LAN (Optional)
􀁨 Realtek® 8100C / 8110S (Optional)
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s, 100Mb/s and 1000Mb/s (1000Mb/s for 8100S only).
- Compliance with PCI 2.2.
- Supports ACPI Power Management.
