Built for high performance computing, this Intel SE7501CW2 Server Motherboard Kit offers versatility and processing power for small and medium-sized businesses! Included with this Intel Server Motherboard are two pre-installed Intel Xeon 2.4 GHz Socket 604 processors with copper heat sinks!

This Intel SE7501CW2 Dual Xeon Server Motherboard features the Intel E7501 chipset, 400/533 MHz front side bus and supports up to 8 GB DDR200/DDR266 of system memory!

Video is provided by the ATi Rage XL PCI integrated video controller and the integrated ATA-100 IDE controllers delivers versatile storage options! This Intel board supports two Intel PRO integrated network connections via 82550PM Fast Ethernet controllers and 82540EM Gigabit Ethernet controller!

Expand your connectivity with three independent PCI buses, up to five total slots that includes one 64-bit/133 MHz PCI-X slot, two 64-bit/100 MHz PCI-X slots and two 32-bit/33 MHz PCI slots!

Build a powerful server system with this Intel SE7501CW2 Dual Xeon Server Motherboard Kit!

• Intel SE7501CW2 Dual Xeon Server Motherboard Features:
• Intel E7501 chipset
• SSI Entry E-Bay 3.0 (fits in many ATX compliant tower chassis)
• 400/533 MHz Front Side Bus
• Supports up to 8 GB Registered ECC DDR200/DDR266
• ATi Rage XL SVGA PCI integrated video controller with 8 MB of video memory
• Two (2) ATA-100 IDE controllers
• One (1) floppy disk controller
• One (1) Intel PRO/100 server network via 82550PM Fast Ethernet controller
• One (1) Intel PRO/1000 Network connection via 82540EM Gigabit Ethernet controller
• Winbond 83627HF with integrated hardware monitoring
• Dual memory channels for improved performance


• Expansion Slots:
• One (1) 64-bit/133 MHz PCI-X slot
• Two (2) 64-bit/100 MHz PCI-X slots
• Two (2) 32-bit/33 MHz PCI slots
• Four (4) 184-pin DIMM sockets


• I/O Ports:
• Two (2) PS/2 ports
• One (1) 15-pin VGA connector
• One (1) 9-pin serial port
• One (1) 25-pin Parallel port
• Three (3) USB ports
• Two (2) RJ-45 Ethernet jacks


• BIOS Features:
• Intel FWH, Flash EEPROM with Phoenix BIOS
• Multiboot BBS (BIOS Boot Specifications) 1.4 compliant


• Server Monitoring:
• Temperature
• Voltage
• Fans


• Supported Processors:
• Intel Xeon with up to 2 MB Cache and 400 or 533 MHz system bus


• Regulatory Approvals:
• cULus
• CE
• Gost-R
• C-Tick
• BSMI
• MIC


• Intel Xeon 2.4 GHz 533 MHz 512 KB Socket 604 CPU Features:
• Intel Xeon 2.80 GHz processor
• 400 MHz bus speed
• 512 KB L2 cache
• 1.50V
• Socket 604
• Includes Copper Heat Sinks

• Intel SE7501CW2 Intel E7501 Socket 604 Server Motherboard
• Two (2) Intel Xeon 2.4 GHz 400 MHz 512 KB Socket 604 CPUs

• Notes:
• Motherboard model: SE7501CW2
• Manual, I/O shield and cables are not included


• Product Requirements:
• RAM
• Case for server motherboard
• Power supply
• Manual, I/O shield and cables
• The rest of the system
