| CPU |
º Socket 754 for AMD Athlon™ 64/Sempron™ processor
º High-performance Hyper Transport CPU interface.
º Support transfer rate of 1600/800/400 mega-transfers per second
|
| CHIPSET |
º North Bridge: SiS® 761GX
º South Bridge: SiS® 965L
|
| GRAPHICS |
º Integrated SiS Mirage 1 2D/3D Graphics
º Share memory: up to 128MB
|
| MEMORY |
º 2 x 184-pin DDR DIMM socket support up to 2 GB
º Support DDR333/266/200 DDR SDRAM
Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS.
For Windows® 64-bit OS with 64-bit CPU, there is no such limitation
|
| EXPANSION SLOT |
º 1 x PCI Express x16 slot
º 1 x CNR slot
º 2 x PCI slots
|
| STORAGE |
º 4 x Ultra DMA133/100/66 devices
• 2 x Serial ATA devices
• RAID0 & RAID1 configuration
|
| AUDIO |
º ADI AD1888 6-channel audio CODEC
º Compliant with AC'97 2.3 specification
|
| LAN |
º Realtek RTL8201CL 10/100 Mbps Fast Ethernet PHY
|
| REAR PANEL I/O |
º 1 x PS/2 keyboard & PS/2 mouse connectors
º 4 x USB ports
º 1 x VGA port
º 1 x RJ45 LAN connector
º 1 x Parallel port (LPT)
º 1 x Serial port (COM1)
º 1 x Audio port (Line-in, Line-out, Mic-in)
|
| INTERNAL I/O CONNECTORS & HEADERS |
º 1 x 24-pin ATX Power Supply connector
º 1 x 4-pin ATX 12V connector
º 1 x FDD connector
º 2 x IDE connectors
º 2 x Serial ATA connectors
º 2 x USB 2.0 headers support additional 4 USB 2.0 Ports
º 1 x SPDIF out header
º 1 x Front panel switch/LED header
º 1 x Front panel audio header
º 1 x IrDA for SIR header
º 1 x Speaker header
º 1 x CD in header
º CPUFAN/SYSFAN connectors
|
| SYSTEM BIOS |
º AMI BIOS with 4Mb Flash ROM
º Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
º Supports ACPI revision 1.0 specification
|
| FORM FACTOR |
º Micro-ATX Size, 244mm*204mm
|
