Witam, mam na sprzedaż płytę główną MSI MS-6330 LE3 wraz z procesorem Duron 1,6 i pamięcia Ram 256MB. Zestaw ma troche lat, ale jest sprawany i może sie komuś przyda. Specyfikacja ze strony producenta:
Chipset • VIA® KT133A Chipset - FSB @200 / 266MHz - AGP 4x and PCI Advanced high performance memory controller - Supports PC100/133 DRAM, & VCM technology • VIA® VT82C686B Chipset - Enhanced Power Management Features - Integrated Super I/O (FDC/LPT/COM 1&2/IR) - Dual bus Master IDE Ultra DMA33/66/100 - Integrated Hardware Soundblaster - DirectSound AC'97 Audio - ACPI
FSB • Supports 100/133MHz FSB (200/ 66MHz Internal System Bus)
Main Memory • Supports three 168-pin unbuffered DIMM using six memory banks. • Supports a maximum memory size of 1.5GB (32M x 8). • Supports 3.3v DRAM DIMM.
Slots • One AGP (Accelerated Graphics Port) slot. - AGP specification compliant - Supports AGP 1x/2x/4x • One CNR (Communication Network Riser) slot. • Five 32-bit Master PCI Bus slots • Supports 3.3v/5v PCI Bus Interface.
On-Board IDE • An IDE controller on the VIA® VT82C686B Chipset provides IDE HDD / CD-ROM with PIO, Bus Master and Ultra DMA33/66/100 operation modes. • Can connect up to four IDE devices.
Audio
• Chip Integrated DirectSound AC'97 Audio
On-Board Peripherals
• On-Board Peripherals include: - 1 Floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. - 2 Serial ports (COM A + COM B) - 1 Parallel port supports SPP/EPP/ECP mode - 4 USB ports (2 Rear Connectors/ USB Front Pin Header) - 1 IrDA connector for SIR/CIR/ASKIR/HPSIR. - 1 Audio/Game port
BIOS • The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically. • The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.
