| Processor |
AMD Sempron™ , Athlon™ 64, Athlon™ 64x2, Athlon™ 64FX, Socket AM2 |
| Chipset |
NVIDIA nForce 570 SLI |
| Front Side Bus |
2000MT/s HyperTransport™ |
| Memory |
Dual channel DDR2 800 / 667 / 533 x 4 DIMMs, Max 8GB |
| VGA on Die |
N/A |
| Expansion Slots |
2 x PCIe x16, 2 x PCIe x1, 2 x PCI |
| IDE |
ATA133 x 2 |
| Serial ATA(SATA)/RAID |
Serial ATA II x 7 + E-Serial ATA II x 1 with RAID 0, 1, 0+1, 5 |
| Audio |
7.1 channel, Realtek ALC882H (HDA) |
| LAN |
Dual Marvell 88E1116 PHY |
| IEEE1394 |
1394a x 2 (VT6308P) |
| Back Panel I/O Ports |
1 x PS/2 keyboard
1 x PS/2 mouse
1 x 1394a
1 x S/PDIF Coax out
4 x USB 2.0
2 x RJ45
1 set 7.1 channel Audio jacks (6 jacks)
1 x Parallel
1 x eSerial ATA (reserve)
1 x S/PDIF Fibre out
|
| Internal I/O Connectors |
3 x USB 2.0 headers, support 6 ports
1 x WOM (reserve)
1 x COM2
1 x Speaker
1 x Front panel
1 x Buzzer
1 x 1394a
1 x CD IN
1 x IRDA
1 x RM
|
| BIOS Features |
LPC-4Mb, ACPI 1.0b, APM 1.2, PnP 1.0a, SMBIOS 2.3, USB 2.0, WfM 2.0 |
| Support CD |
Drivers, Super Utilities, DirectX, Adobe Reader, Norton Internet Security, Manual & Raid Manual |
| Standards/Manageability |
USB 2.0, WfM 2.0, DMI 2.0, WOL by PME, LPC 1.1 Interface |
| Special Features |
Special cooling, CnQ, nView, nTune, HDA, SuperRecovery, SuperBoot, SuperBIOS-Protect, SuperSpeed, SuperStep, SuperLogo, SuperUpdate,
Humanity Technology
|
| Form Factor |
ATX (12" x 9.6")
|
