CPU

º Socket 478 for latest Intel Pentium 4 / Celeron processor
º FSB 533*/ 400MHz (* means overclocking)

CHIPSET

º SiS^® 650GL & 962L
º North Bridge: SiS^® 650GL
º South Bridge: SiS^® 962L
º SiS^® 962/L South Bridge

MEMORY

º 2 x 184-pin DDR DIMM socket support up to 2 GB
º Support DDR333/266/200 DDR SDRAM
Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS.
For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation

EXPANSION SLOT

º 3 x PCI slots
º 1 x CNR slot

STORAGE

º Support by SiS^® 962L
    • 4 x Ultra DMA133/100/66 devices

AUDIO

º C-Media CMI9738 4-channel audio CODEC
º Compliant with AC'97 2.2 specification

LAN

º Realtek RTL8100B 10/100 Mbps Fast Ethernet Controller

REAR PANEL I/O

º 1 x PS/2 keyboard & PS/2 mouse connectors
º 2 x USB ports
º 1 x RJ45 LAN connector
º 1 x VGA port
º 1 x Parallel port (LPT)
º 1 x Serial port (COM1)
º 1 x Game port
º 1 x Audio port (Line-in, Line-out, Mic-in)

INTERNAL I/O CONNECTORS & HEADERS

º 1 x 20-pin ATX Power Supply Connector & 4-pin 12V Connector
º 1 x FDD connector supports one 360K~2.88MB FDD
º 2 x IDE connectors
º 1 x IrDA for SIR header
º 1 x Speaker header
º 1 x COM port header (COM2)
º 2 x USB 2.0 headers support additional 4 USB 2.0 Ports
º 1 x Front panel switch/LED header
º 1 x Front panel audio header
º 1 x CD in header
º CPUFAN/PWRFAN/CASFAN connectors
º WOL/WOM connectors

FORM FACTOR & LAYERS

º Micro-ATX Size (244mm*244mm), 4 Layers
