Model

Brand

ASUS

Model

PC-DL Deluxe

Supported CPU

CPU Socket Type

Dual 603/604

CPU Type

Dual Intel Xeon

System Bus

533/400MHz

Chipsets

North Bridge

Intel 875P

South Bridge

Intel ICH5R

Memory

Number of DDR Slots

4 x 184Pin

DDR Standard

DDR 333 (PC 2700)

Maximum Memory Supported

4GB

Channel Supported

Dual Channel

Expansion Slots

AGP Slots

1 x AGP 4X / 8X

PCI Slots

5

Storage Devices

PATA

2 x ATA 100 4 Dev. Max

Additional PATA

1 x ATA 133 2 Dev. Max

SATA

2 x SATA 1.5Gb/s

SATA RAID

0/1

Additional SATA

2 x SATA 1.5Gb/s

Additional SATA RAID

0/1/0+1

Additional RAID Controller

Promise PDC20378

Onboard Video

Onboard Video Chipset

None

Onboard Audio

Audio Chipset

AD1985

Audio Channels

6 Channels

Onboard LAN

LAN Chipset

Intel 82547EI

LAN Speed

10/100/1000Mbps

Max LAN Speed

10/100/1000Mbps

Rear Panel Ports

PS/2

2

COM

2

LPT

1

USB 1.1/2.0

4 x USB 2.0

IEEE 1394

1 x IEEE 1394a

Audio Ports

3 Ports

Onboard USB

Onboard USB

4 x USB 2.0

Onboard 1394

Onboard 1394

1 x 1394a

Physical Spec

Form Factor

ATX

Dimensions (W x L)

12" x 9.6"

MASKOWNICA W ZESTAWIE

w zestawie

- płyta główna

- maskownica blaszana na porty
