General

CPU

- Socket 478, Intel^® Pentium^® 4/Celeron
- FSB Spec. 400MHz, Max. 533MHz(over-clocking)

Chipset

- Intel^® 845GL

Memory

- Max. 2GB DDR or 2GB SDRAM
- DDR 2 x DDR, DDR266/200 non-ECC, un-buffered memory
- SDRAM 2 x SDRAM, PC133/100 non-ECC, un-buffered memory

BIOS

- 2Mb AMI BIOS with ACPI, SM BIOS 2.3.0, PnP

Audio, Video and Networking

Graphics

- Chip Int. Intel^® Extreme Graphics
- Memory Max. 64MB

Audio

- Chip AC97 CODEC
- Channel 5.1 CH

LAN

- 802.3u, 10/100 Ethernet PCI LAN, WOL supported
- Supports PXE

Expansion / Connectivity

Slots

- PCI 3 slots, PCI 2.2
- AMR 1 shared w/PCI 3

Connector

- IDE 2 x ATA 100/66/33
- Floppy 1 connector
- SIR/CIR 1/0
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- CD/AUX/ audio in
- Front panel audio connector

Rear Panel I/O

ASROCK I/O
- Keyboard PS2 x1
- Mouse PS2 x1
- USB2.0 4 ports default on rear panel + 2 ports upgrade via header
- Serial 1 COM Port Bracket
- Parallel 1
- Game/MIDI 1
- LAN 1 x RJ45
- Audio I/O Line In/Line Out/Mic.
- VGA x 1

Other Features / Miscellaneous

Unique Feature

- ASRock U-COP

Form Factor

- MicroATX
