| Product Specifications |
| General |
| CPU |
- Socket AM2 for AMD Athlon™ 64FX / 64X2 / 64 and Sempron processors |
| - AMD LIVE!™ Ready |
| - Supports AMD's Cool 'n' Quiet Technology |
| - FSB 1000 MHz (2.0 GT/s) |
| - Supports Untied Overclocking Technology |
| - Supports Hyper-Transport Technology |
| Chipset |
- NVIDIA® GeForce 6100 / nForce 430 or GeForce 6150SE / nForce 430 |
| Memory |
- Dual Channel DDR2 memory technology |
| - 4 x DDR2 DIMM slots |
| - Supports DDR2 800/667/533 non-ECC, un-buffered memory |
| - Max. capacity of system memory: 8GB* |
| *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® XP and Windows® Vista™. For Windows® XP 64-bit and Windows® Vista™ 64-bit with 64-bit CPU, there is no such limitation. |
| BIOS |
- 4Mb AMI BIOS |
| - AMI Legal BIOS |
| - Supports "Plug and Play" |
| - ACPI 1.1 Compliance Wake Up Events |
| - Supports Jumperfree |
| - SMBIOS 2.3.1 Support |
| Audio, Video and Networking |
| Graphics |
- Integrated NVIDIA® GeForce6-class graphics |
| - DX9.0 VGA, Pixel Shader 3.0 |
| - Max. shared memory 256MB |
| - Dual VGA Output: Support D-Sub and DVI-D ports with DVI Graphics-SI Card by independent display controllers |
| Audio |
- 7.1 CH Windows® Vista™ Premium Level HD Audio (ALC888 Audio Codec) |
| LAN |
- Gigabit LAN 10/100/1000 Mb/s |
| - Giga PHY Realtek RTL8211B |
| - Supports Wake-On-LAN |
| - Supports PXE |
| Expansion / Connectivity |
| Slots |
- 2 x PCI slots |
| - 1 x PCI Express x16 slot |
| - 1 x PCI Express x1 slot |
| - 1 x HDMR slot |
| Connector |
- 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5, JBOD), NCQ, and Hot Plug functions |
| - 1 x ATA133 IDE connector (supports 2 x IDE devices) |
| - 1 x Floppy connector |
| - 1 x IR header |
| - 1 x Game header |
| - 1 x COM port header |
| - 1 x HDMI_SPDIF header |
| - CPU/Chassis FAN connector |
| - 20 pin ATX power connector |
| - 4 pin 12V power connector |
| - CD in header |
| - Front panel audio connector |
| - 3 x USB 2.0 headers (support 6 USB 2.0 ports) |
| Rear Panel I/O |
HD 8CH I/O |
| - 1 x PS/2 Mouse Port |
| - 1 x PS/2 Keyboard Port |
| - 1 x VGA Port |
| - 1 x Parallel Port (ECP/EPP support) |
| - 4 x Ready-to-Use USB 2.0 Ports |
| - 1 x RJ-45 Port |
| - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone |
| Other Features / Miscellaneous |
| Unique Feature |
Hybrid Booster: |
| - CPU Frequency Stepless Control |
| - ASRock U-COP |
| - Boot Failure Guard (B.F.G.) |
| - ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5% |
| Support CD |
- Drivers, Utilities, AntiVirus Software (Trial Version) |
| Accessories |
- Quick Installation Guide, Support CD, I/O Shield |
| - Floppy/ATA 133 Cables |
| - 1 x SATA Data Cable |
| - 1 x SATA 1 to 1 Power Cable |
| - 1 x COM Port Bracket |
| - 1 x HDMR card |
| - 1 x HDMI_SPDIF Cable |
| - 1 x DVI Graphics-SI Card |
| Hardware Monitor |
- CPU Internal Temperature Sensing |
| - CPU Ambient Temperature Sensing |
| - Chassis Temperature Sensing |
| - CPU Fan Tachometer |
| - Chassis Fan Tachometer |
| - CPU Quiet Fan |
| - Voltage Monitoring: +12V, +5V, +3.3V, Vcore |
| Form Factor |
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm |
| OS |
- Microsoft® Windows® 2000 / XP / XP Media Center / XP 64-bit / Vista™ / Vista™ 64-bit compliant |
| Certifications |
- FCC, CE, WHQL |
