Dual HVD SCSI PCI card

LSI Logic LSI22802 / Symbios SYM22802 Dual HVD SCSI PCI card

Product Description

LSI Logic LSI22802

Overview

The LSI22802 provides two channels of Ultra SCSI connectivity for Intel systems. It is designed for servers and clustered environments.

Features

True multi-function device (per PCI 2.1 Specification)

Uses only one PCI slot

Functions as one 32-bit PCI DMA bus master

Two independent DMA channels with internal programmable arbitration

33 MHz PCI bus zero wait state operation

Maximum burst transfer rate of 132 MBps

Supports PCI write and invalidate, read line, and read multiple commands

Universal 3.3V and 5V PCI

16-bit Ultra SCSI design based on the popular LSI53C875 for maximum performance

Local memory bus for FLASH memory BIOS storage

SCSI TolerANT active negation SCSI driver and receiver technology

SCAM (SCSI Configured AutoMatically) Level 1 functionality for SCSI plug-and-play support

External VHDCI SCSI connector per channel 16-bit internal/16-bit external
