SPECIFICATIONS

Essentials

StatusLaunched

Launch DateQ3'09

Processor NumberX3430

# of Cores4

# of Threads4

Clock Speed2.4 GHz

Max Turbo Frequency2.8 GHz

Intel® Smart Cache8 MB

DMI2.5 GT/s

Instruction Set64-bit

Instruction Set ExtensionsSSE4.2

Embedded Options Available Yes

Lithography45 nm

Max TDP95 W

VID Voltage Range0.6500V-1.4000V

Recommended Customer PriceTRAY: $228.00

BOX : $203.00

Additional Information URLLink

Memory Specifications

Max Memory Size (dependent on memory type)32 GB

Memory TypesDDR3-800/[zasłonięte]/1333

# of Memory Channels2

Max Memory Bandwidth21 GB/s

Physical Address Extensions36-bit

ECC Memory Supported ‡ Yes

Expansion Options

PCI Express Revision2.0

PCI Express Configurations ‡1x16, 2x8, 4x4

Max # of PCI Express Lanes1

Package Specifications

Max CPU Configuration1

TCASE72.7°C

Package Size37.5mm x 37.5mm

Processing Die Size296 mm2

# of Processing Die Transistors774 million

Sockets SupportedLGA1156

Low Halogen Options AvailableSee MDDS

Advanced Technologies

Intel® Turbo Boost Technology ‡Yes

Intel® vPro Technology ‡ No

Intel® Hyper-Threading Technology ‡ No

Intel® Virtualization Technology (VT-x) ‡ Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Intel® 64 ‡ Yes

Idle StatesYes

Enhanced Intel SpeedStep® Technology Yes

Intel® Demand Based Switching Yes

Thermal Monitoring TechnologiesNo

Intel® Data Protection Technology

AES New Instructions No
