NOWA PŁYTA GŁÓWNA

ASUS P5P800

socket 478

- Intel Dual-Core & Pentium 4 CPU

- Intel 865PE chipset
- AGP8X
- Dual-Channel DDR400
- ASUS Hyper Path Technology
- Intel Gigabit LAN
- 6 Channel Audio
- Serial ATA

CPU

Intel Socket 775 Pentium® D/Pentium® 4/Celeron Processors

Compatible with Intel® 05B/ 05A and 04B/04A processors

Support Intel® EM64T/ EIST/ Hyper-Threading Technology

Chipset

Intel 865PE

Intel ICH5

Front Side Bus

800/533/ MHz

Memory

4 x184-pin DIMM, Max. 4 GB, DDR 400/333/266 SDRAM ,Non-ECC,Un-buffered Memory

Dual Channel memory architecture

ASUS Hyper-Path Technology

Expansion Slots

4 x PCI

1 x AGP 8x / 4X (0.8V, 1.5V only)

Storage

Southbridge

2 xUltraDMA 100/66/33

2 xSATA 3 Gb/s ports

USB

8 USB 2.0 ports

Audio

ADI AD1888 SoundMAX 6 -Channel audio CODEC

S/PDIF out on back I/O port

LAN

Intel 82540EM Gigabit/ LAN Controller supporting BASE-T Ethernet 100/10

Overclocking Features

Intelligent overclocking tools

- ASUS CPU Lock Free

- AI Overclocking (intelligent CPU frequency tuner)

- CPU and Memory voltage adjustable

SFS (Stepless Frequency Selection)

- FSB tuning from 100MHz up to 400MHz at 1MHz increment

- Adjustable FSB/DDR ratio. Fixed AGP/PCI frequencies

Overclocking Protection

- ASUS C.P.R.(CPU Parameter Recall)

Special Features

ASUS MyLogo

ASUS EZ Flash

ASUS CrashFree BIOS 2

ASUS Q-Fan

Back Panel I/O Ports

1 x Parallel

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x Serial port

1 x S/PDIF Out

1 x LAN(RJ45) port

4 x USB 2.0/1.1

6 -Channel Audio I/O

Internal I/O Connectors

2 x USB connectors supports additional 4 USB 2.0 ports

1 x Floppy disk drive connector

2 x IDE connector

2 x SATA connectors

1 x CPU Fan connector

1 x Chassis Fan connector

1 x Power Fan connector

1 x S/PDIF Out connector

1 x4-pin ATX 12V Power connector

24 -pin ATX Power connector

Front panel audio connector

Game/MIDI port connector

Chassis Intrusion connector

CD/AUX audio in

System Panel Connector

BIOS

4 Mb Flash ROM

DMI 2.0

AMI BIOS

PnP

WfM 2.0

Manageability

WOL/WOR by PME，Chasis Intrusion,PXE,RPL，

Support Disc

Drivers

ASUS PC Probe

Anti-virus software (OEM version)

ASUS LiveUpdate Utility

Accessories

User's manual

x IDE cables

x UltraDMA 133/100/66 cables

x Floppy disk drive cables

x SATA cables

SATA power cables

I/O Shield

Form Factor

ATX Form Factor

12 inch x 8.4 inch ( 30.5 cm x 21.3 cm )

MASKOWNICA W ZESTAWIE
