CPU

• Supports Intel® Pentium® 4 processor in 478 pin package.
• Supports 1.5GHz, 1.6GHz, 1.7GHz, 1.8GHz, 1.9GHz, 2.2GHz and up.

Chipset

• Intel® 845 Chipset
- Supports DDR DRAM at 200/266MHz operation (DDR200/DDR266).
- AGTL+ host bus with integrated termination supporting 32-bit host addressing.
- 1.5V AGP interface with 4x data transfer and 4x fast write capability.
- 8-bit, 66MHz 4x hub interface to the Intel ICH2.

• Intel® ICH2 Chipset
- Upstream hub interface for access to the Intel MCH.
- 2-channel Ultra ATA/100 Bus Master IDE controller.
- USB controller 1.1 (expanded capabilities for 4 ports, 2/2 rear/front).
- I/O APIC.
- SMBus controller.
- FWH interface.
- LPC interface.
- AC'97 2.1 interface.
- PCI 2.2 interface.
- Integrated system management controller.

FSB

• Support 100MHz FSB
• Support 400MHz Intel NetBurst micro-architecture bus.

Main Memory

• Supports four memory banks using two 184-pin DDR DIMM.
• Supports up to 2GB PC2100/PC1600 DDR DRAMs.
• Supports 2.5v DDR DRAM.

Slots

• One AGP (Accelerated Graphics Port) 4x slot (1.5V only).
• Three PCI 2.2 32-bit Master PCI bus slots (support 3.3V/5V PCI bus interface).
• One CNR (Communication Network Riser) slot.

Note: The AGP slot DOES NOT support 3.3V AGP card. Use of 3.3V AGP card may cause damage to the motherboard.

On-Board IDE

• An IDE controller on the ICH2 chipset provides IDE HDD/CD-ROM with PIO, Bus Master and
  Ultra DMA 33/66/100 operation modes.
• Can connect up to four IDE devices.

Audio

• AC'97 link controller integrated in ICH2 chipset.
• 2-channel software audio codec AD1885.

Network

• PCI local bus single-chip Fast Ethernet Controller, RealTek RTL8100L. (optional)
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10Mb/s and 100Mb/s auto-negotiation operation.
- Compliance with PCI v2.2/PC99 standard.
- Supports Wake-On-LAN and remote wake-up.
- Supports ACPI power management.

On-Board Peripherals

• On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
- 2 serial ports (COM A + COM B).
- 1 parallel port supports SPP/EPP/ECP mode.
- 4 USB ports (Rear x 2 / Front x 2).
- 1 IrDA connector for SIR.
- 1 RJ-45 LAN jack. (For MS-6507-L only)
- 1 audio/game port.

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and
  expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface (DMI) function which records your
  motherboard specifications.

Dimension

• 24.3 cm(L) x 23.1 cm(W) MicroATX Form Factor

Mounting

• 6 mounting holes.
