CPU

• Supports Socket A (Socket 462) for AMD® Athlon™ XP/Athlon™/Duron™ processor
• Supports 800MHz up to Athlon™ XP 2800+ processor

Chipset

• VIA® KT333 Chipset
- FSB @200/266/333 MHz
- Supports DDR200/266/333 memory
- AGP 4X and PCI advanced high performance memory controller.

• VIA® VT8235 Chipset
- Integrated Direct Sound AC'97 audio
- Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller
- ACPI & PC2001 compliant enhanced power management
- Integrated USB 2.0 controller

FSB

• 100/133/166(200/266/333)MHz clocks are supported.

Main Memory

• Supports six memory banks using three 184-pin DDR DRAMs.
• Supports up to 3GB memory size.
• Supports DDR333/DDR266/DDR200 DRAM
• No support ECC Function.

Slots

• One AGP (Accelerated Graphics Port) 1.5V 4x slot
• Six 32-bit PCI bus slots (support 3.3v/5v PCI bus interface)
• One CNR (Communication Network Riser) slot

On-Board IDE

• An IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with PIO,
Bus Master and Ultra DMA133/100/66/33 operation modes
• Can connect up to four IDE devices

Audio

• RealTek ALC650 6-channel audio
- Bundle MSI DVD 5.1 Channel (Optional)

LAN

• VIA VT6103 LAN controller

On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 2 serial ports (COM A + COM B)
- 1 parallel port supports SPP/EPP/ECP mode
- Vertical audio ports
- 1 SPDIF output (2 x 6) with housing (Optional)
- 6 USB ports (Rear x 4/ Front x 2)

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and
expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your
motherboard specifications.

Dimension

• 30.5 cm(L) x 21 cm(W) ATX Form Factor
