Main Memory

• Supports Dual DDR2 400/533/667/800
- 2 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 4GB.

Slots

• 1 PCI Express x16 slot
• 1 PCI Express x1 slot
• 2 PCI slots, support 3.3V/ 5V PCI bus Interface.

On-Board IDE

• One IDE port by AMD® SB600
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices

On-Board SATA

• 4 SATA II ports by AMD® SB600
- Supports storage and data transfers at up to 3Gb/s

RAID Function

- SATA II 1~4 supports RAID 0, 1 and 0+1 mode by AMD® SB600

MSI Reminds You... • The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.

Audio

• Chipset integrated by Realtek® ALC888
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Supports 10/100 Fast Ethernet by Realtek 8101E (K9AGM2-L)
• Supports 10/100/1000 Fast Ethernet by Realtek 8111B (K9AGM2-F)

Internal I/O Connectors

- ATX 24-pin power connector
- ATX 4-pin 12V CPU power connector
- CPU / System FAN connectors
- Chassis intrusion switch connector
- Front panel audio connector
- Front panel connector
- Clear CMOS jumper
- 1 X CD-in connector
- 1 X SPDIF out connector (optional)
- 1 X SPDIF in connector (optional)
- 1 x TV-out connector (optional)
- 3 x USB 2.0 connector support additional 6 ports
- 1 x Floppy disk drive connector
- 4 x Serial ATA II connectors
- 1 x ATA133 connector

MSI Reminds You... • The floppy disk cable will be optional.

Back Panel I/O Ports

- 1 x Parallel port
- 1 x PS/2 keyboard
- 1 x PS/2 mouse
- 1 x 6 in 1 audio jack
- 4 x USB 2.0 ports
- 1 x RJ45 LAN jack
- 1 x VGA port

Dimension

• 24.4cm(L) x 21.5cm(W) Micro-ATX Form Factor

Mounting

• 6 mounting holes.

Faktura VAT na życzenie,dostępne od ręki,w komplecie płyta w opakowaniu zastępczym .Sterowniki i manual. Kontakt:mejl , gsm 791-[zasłonięte]-377
