| Sensor |
"Exmor" APS HD CMOS Sensor |
| Sensor Size |
0 °C to 40 °C (32 °F to 104 °F) |
| Total Pixels |
16.7 megapixels |
| Effective Pixels |
Approx. 13.6 megapixels (16:9)
Approx. 16.1 megapixels (3:2) |
| Crop Factor |
1.6x |
| Minimum Illumination |
7 lx (w/ SELP18200Lens, 1/24 shutter speed, Auto IRIS, Auto GAIN) [60i]
7 lx (w/ SELP18200Lens, 1/25 shutter speed, Auto IRIS, Auto GAIN) [50i]) |
| Lens Mount |
E-mount |
| Recording Format |
MPEG-4 AVC/H.264 AVCHD 2.0 format compatible (HD)
MPEG-2 PS (SD) 7 |
| Audio Recording Format |
Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz (HD)
Dolby Digital 2ch, 16bit, 48kHz (SD/STD) |
| 60Hz Recording Mode |
HD PS (28Mbps) 1920x1080/60p
HD FX (24Mbps) 1920x1080/60i
HD FH (17Mbps) 1920x1080/60i
HD HQ (9Mbps) 1440x1080/60i
HD LP (5Mbps) 1440x1080/60i
HD FX (24Mbps) 1920x1080/24p
HD FH (17Mbps) 1920x1080/24p
HD FX (24Mbps) 1920x1080/30p
HD FH (17Mbps) 1920x1080/30p
HD FX (24Mbps) 1280x720/60p
HD FH (17Mbps) 1280x720/60p
SD/STD HQ (9Mbps) 720x480/60i |
| 50Hz Recording Mode |
HD PS (28Mbps) 1920x1080/50p
HD FX (24Mbps) 1920x1080/50i
HD FH (17Mbps) 1920x1080/50i
HD HQ (9Mbps) 1440x1080/50i
HD LP (5Mbps) 1440x1080/50i
HD FX (24Mbps) 1920x1080/25p
HD FH (17Mbps) 1920x1080/25p
HD FX (24Mbps) 1280x720/50p
HD FH (17Mbps) 1280x720/50p
SD/STD HQ (9Mbps) 720x576/50i |
| Recording Media |
Memory Stick
SD/SDHC/SDXC
HXR-FMU128 |
| Shutter Type |
Electronic (video)
Mechanical (stills) |
| Shutter Speed |
Auto
1/60 - 1/10000 (60i, 60p)
1/30 - 1/10000 (30p)
1/48 - 1/10000 (24p, 60i)
1/50 - 1/10000 (50i, 50p)
1/25 - 1/10000 (25p)[50i]
30s-1/4000 (Stills)"
Manual Shutter Speed
1/4 - 1/10000 (60i, 30p, 60p)
1/3 - 1/10000 (24p, 60i)
1/3-1/10000 (50i)
30s-1/4000 (Stills) |
| ISO |
160 - 5000 in 1/2EV steps or Low, Middle, High (Movie)
100 - 25600 in 1/2EV steps or Low, Middle, High (Stills) |
| Auto ISO Limit |
160 - 4000 in 1/2EV steps (Movie)
100 - 2500 in 1/2EV steps (Stills) |
| Gain |
Auto/Manual (L,M,H or 0dB - 30dB in 3dB steps) |
| AGC (Automatic Gain Control) |
0dB - 27dB in 3dB steps |
| White Balance |
Auto/Manual (2300 - 15000K in 100K steps) |
| Black Level |
-15 - +15 |
| Auto Black Balance |
Yes |
| Gamma |
Standard, Still, Cinematone1, Cinematone2, ITU709 |
| Color Modes |
Standard, Still, Cinematone1,Cinematone2, PRO, ITU709 MATRIX |
| Picture Profile |
PP1 - PP6, OFF |
| Focus System |
Auto/Manual |
| Face Detection |
Focus Control, Face Touch, Auto Control, Bit Allocation on Face |
| Steady Shot |
Movie: Active, Standard, OFF
Stills: Standard, OFF |
| Zoom |
x1.0 - x2.0 (Lossless Digital Zoom) |
| GPS |
Yes (ON/OFF) |
| Color Bar |
Yes (ON/OFF) |
| Tone |
Yes (ON/OFF) |
| Timecode |
Drop Frame and Non-Drop Frame |
| Timecode Output |
HDMI |
| Built-in Mic |
Yes (stereo) |
| Remote Control |
IR
LANC (x1) |
| Power Requirements |
7.6V/7.2V (AC Adapter/Battery) |
| Power Consumption |
5.4W (with SELP18200 Lens) |
| Operating Temperature |
32 to 104° F (0 - 40° C) |
| Storage Temperature |
-4 - +140° F (-20 - +60° C) |
| Dimensions (WxHxD) |
Body only: 5.63 x 8 x 11.25" (14.3 x 20.32 x 28.58 cm)
With SELP18200 Lens: 5.63 x 8 x 17" (14.25 x 20.3 x 42.95 cm) |
| Weight |
3.79 lb (1.72 kg) |
| Display |
| LCD Monitor |
3.46" (8.8cm) XtraFine LCD (16:9 ratio) |
| Movements |
Opening Angle: 90°
Rotating Angle: 270° |
| Touch Panel |
Yes |
| Brightness |
Normal/Bright |
| Zebra |
Yes (70 - 100% in 5% steps) |
| Markers |
Yes (OFF, 4:3, 13:9, 14:9, 15:9, 1:66:1, 1.85:1, 2.35:1) |
| Histogram |
Yes (OFF/ON/ON Zebra Point) |
| Audio Level Display |
Yes (ON/OFF) |
| Playback Zoom |
Stills Only |
| Inputs/Outputs |
| HDMI Output |
Yes (Type A) |
| Component Out |
Yes (RCA x3) |
| Video Output |
Yes (RCA x1) |
| Audio Output |
Yes (RCA x2) |
| Audio Input |
XLR (3-Pin x2) (LINE, MIC, MIC +48V) |
| Headphone |
Yes (CH1, CH2, STEREO/MIX) |
| Speaker |
Yes (16 step volume control) |
| USB |
Yes (mini AB) |
| Accessory Shoe |
Hot Shoe |
| Memory Card Slot |
SD/MS (x1)
FMU Slot (x1) |
| Lens |
| Focal Length |
18 - 200mm |
| Zoom Operation |
Servo/Manual |
| Aperture |
Maximum: f/3.5 - 6.3
Minimum: f/22 - 40 |
| Number of Aperture Blades |
7 |
| Mount |
Sony E-Mount |
| Filter Thread |
67 mm |
| Minimum Focus Distance |
1.0' (30.48 cm) |
