| Socket |
775 |
| Chipset |
Intel® 915G |
Złącza SATA / ATA
|
- 2x ATA UltraDMA 133/100
- 4x SATA
|
| USB |
2szt. |
| Format |
ATX |
| Karta dźwiękowa |
32-bit |
| Karta Graficzna |
HD 256-bit intel 900 |
| Karta Sieciowa |
10/100 Mbit/s Realtek |
| Złącza rozszerzeń |
1x PCI-E x16
2x PCI-E x1
4x PCI
|
| Pamięć |
2 x DDR MAX - 2GB |
General
Product TypeMotherboard
Form FactorATX
Width30.5 cm
Depth24.4 cm
Compatible ProcessorsPentium 4, Celeron D
Processor SocketLGA775 Socket
Supported Processor PackagingFC-LGA4
Chipset TypeIntel 915G Express
Max Bus Speed800 MHz
BIOS TypePhoenix
Storage ControllerATA-100, Serial ATA-150
Processor
Installed Qty (Max Supported)0 ( 1 )
Memory
Supported RAM TechnologyDDR II SDRAM
RAM Installed ( Max )0 MB / 8 GB (max)
Supported RAM SpeedPC2-3200, PC2-4300
RAM FeaturesUnbuffered, two DDR channels
Video
Graphics ControllerIntel GMA 900
Video MemoryDynamic Video Memory Technology 3.0
Video Memory Installed ( Max )/ 224 MB (max)
Audio
Audio OutputSound card
Audio CodecAD1986
Sound Output ModeStereo
Compliant StandardsAC '97, High Definition Audio
Telecom / Networking
NetworkingNetwork adapter - Broadcom BCM5751 - Ethernet, Fast Ethernet, Gigabit Ethernet
Features
BIOS FeaturesACPI support, APM support, DMI support, SMBIOS support, Hyper-Threading Technology, Multi Boot, USB Security
Hardware MonitoringCPU core temperature, chassis temperature, CPU fan tachometer, power supply fan tachometer
Sleep / Wake UpWake on LAN (WOL)
Hardware FeaturesGreen Edition, Safe Standby
Expansion / Connectivity
Expansion Slot(s)4 memory ( 1.8 V ) - DIMM 240-pin
1 processor - LGA775 Socket
1 PCI Express x16
2 PCI Express x1
4 PCI ( 3.3 V/ 5 V )
Storage InterfacesATA-100 - connector(s): 1 x 40pin IDC
Serial ATA-150 - connector(s): 4 x 7pin Serial ATA
Interfaces1 x serial - RS-232 - 9 pin D-Sub (DB-9)
4 x Hi-Speed USB - 4 PIN USB Type A
1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
1 x audio - line-In - mini-phone stereo 3.5 mm
1 x audio - line-out - mini-phone stereo 3.5 mm
1 x microphone - input - mini-phone 3.5mm
1 x storage - floppy interface - 34 PIN IDC
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
1 x parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25)
1 x keyboard - generic - 6 pin mini-DIN (PS/2 style)
1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
= 100% SPRAWNY =
= WYSTAWIAMY FAKTURY VAT =
= GWARANCJA 12 MIESIĘCY =
KUPUJESZ W SKLEPIE - OD SUPER SPRZEDAWCY!!!
SPRAWDŹ KOMENTARZE
DOSTAWA W 24H
