NOWA PŁYTA GŁÓWNA

DELL 0WC297

  DS/N CN-0WC[zasłonięte]297-701-5CB-01E4
socket 478

MASKOWNICA W ZESTAWIE

CPU

Support Intel Pentium 4 HT, Prescott P4, Celeron D

Socket Type - Socket 478

Chipset

* Northbridge – Intel 865GV

* Southbridge – Intel ICH5

FSB - 800/533 MHz

Integrated Graphics

Intel Extreme Graphics 2

Memory

2 x 184-pin DDR DIMM slots – DDR 400/333 MHz non-ECC, un-buffered memory (Max 2GB)

Expansion Slots

3 x PCI

Storage

1 x SATA 1.5Gb/s connector

Audio

ADI 198xx

Ethernet

Intel – 10/100Mb/s

Rear Panel

1 x PS/2 for mouse (green)

1 x PS/2 for keyboard (purple)

1 x RJ45 LAN Port

1 x Serial port

1 x Parallel port

4 x USB 2.0 ports

1 x Audio I/O

1 x VGA port

Internal

1 x 4-pin ATX 12V Power connector

1 x 20-pin ATX Power connector

1 x 4-pin CPU Fan connector

1 x Clear Password Jumper

1 x Battery socket (3V)

1 x Front Panel

1 x Floppy header

1 x IDE header

1 x USB header

BIOS

Form Factor

Micro-ATX
