• JGS524: 24 10/100/1000 Mbps twisted-pair RJ-45 ports

Performance

• Switching bandwidth:
  -JGS524: 48 Gbps
• Forward rate (1000 Mbps port): 1,480,000 packets per sec
• Forward rate (100 Mbps port): 148,000 packets per sec
• Forward rate (10 Mbps port): 14,800 packets per sec
• Jumbo frames latency (1000 to 1000 Mbps): 20 μs max
• Packet buffer memory: 2 Mb
• MAC address database: 8,000
• Mean time between failures (MTBF):
  -JGS524: 230,000 hours (~ 26 years
• Acoustic noise: 40 dB

Power Consumption

• 100-240V; 50-60 Hz; plug is localized to country of sale
• JGS524: 16max

Standards Compliance

• IEEE 802.3i 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• IEEE 802.3x flow control

Status LEDs

• Unit: power
• Per network port: Link, activity, speed

Physical Specifications

• Dimensions (h x w x d): 43 x 330x 207 mm (1.7 x 13 x 8.2 in)
• Weight: JGS524: 1.72 kg (3.79 lb)

Environmental Specifications

• Operating temperature: 0° to 50° C (32° to 122° F)
• Operating humidity: 90% maximum relative humidity, non-condensing
• Storage temperature: -20° to 70° C (-4° to 158º F)
• Storage humidity: 10 to 95% relative humidity

Electromagnetic Compliance

• CE mark, commercial
• FCC Part 15 Class A
• VCCI Class A
• EN 55022 (CISPR 22), Class A, EN 50082-1,
• EN 55024
• C-Tick
