IEEE 802.1Q VLAN Tagging
Video VLAN
Voice VLAN - Based on phones OUI bytes (internal database, or usermaintained) or protocols (SIP, H323 and SCCP)

IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
IEEE 802.3i 10BASE-T IEEE 802.3ae 10-Gigabit Ethernet
IEEE 802.3u 100BASE-T IEEE 802.3ad Trunking (LACP)
IEEE 802.3ab 1000BASE-T IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED)
IEEE 802.1Q VLAN Tagging IEEE 802.1p Class of Service
IEEE 802.3x full-duplex flow control IEEE 802.3 af (PoE)

Access Lists
L2 MAC, L3 IP and L4 Port ACLs
Ingress rate limiting
Egress rate limiting
Support for IPv6 fields
Diff Serv QoS
IEEE 802.1p COS
Dst MAC and IP
IPv4 and v6 DSCP
IPv4 and v6 TOS
WRR (Weighted Round Robin)
Strict Priority queue technology
Auto-VoIP
Yes, based on protocols (SIP, H323 and SCCP)
or on OUI bytes (default database and user-based OUIs)
in the phone source MAC address
Auto Video
Port Mirroring

Password management
Configurable Management VLAN
Admin access control via Radius and TACACS+
Web-based graphical user interface (GUI)
Smart Control Center (SCC) for multiswitch management
IPv6 management
Dual Soft ware (firmware) image
Dual Confi guration file
SNTP client over UDP port 123
SNMP v1/v2
SNMP v3 with multiple IP addresses
RMON 1,2,3,9
Port Mirroring
Many to One Port Mirroring
Cable Test utility
SSL/HTTPS and TLS v1.0 for web-based access
TFTP/HTTP File transfers (uploads, downloads)
HTTP Download (firmware)
Syslog (RFC 3164)

L2 Services - Availability
IEEE 802.3ad - LAGs
LACP ( (8 LAGS with max. of 8 members in each LAG))
Broadcast Storm Control
IEEE 802.3x (Full Duplex and flow control)
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree
IEEE 802.1s Multiple Spanning Tree
L2 Services - Multicast Filtering
IGMP Snooping (v1, v2 and v3)
MLD Snooping Support (v1 and v2)
IGMP Snooping queriers
Block unknown Multicast

L3 Services - DHCP
DHCP Client
DHCP Snooping
L3 Services - IPv4 Routing
Static Routing
VLAN Routing

Network Traffic
Access Control Lists (ACLs)
L2 / L3 / L4
IP-based ACLs (IPv4 and IPv6)
MAC-based ACL
TCP/UDP-based ACL
MAC lockdown
MAC lockdown by the number of MACs
IEEE 802.1x Radius Port Access Authentication
Port Security
DHCP Snooping
PoE Timer

440 x 257 x 44 mm

Addressing 48-bit MAC address
1K Multicast groups
32 Static Routes
15 Routed VLANs
1024 ARP Cache entries
8K DHCP snooping bindings
1024 DHCP static entries
480 rules shared for MAC, IP and IPv6 ACLs
Packet size of 9k for Jumbo frame support
