| Specyfikacja techniczna: |
Interfejsy urządzenia
Ethernet WAN
- RJ-45 port, 10/100/1000Mbps, Auto-MDI/MDIX
Ethernet LAN
- RJ-45 port, 10/100/1000Mbps, Auto-MDI/MDIX x 4
USB WAN
- USB 2.0 for 3G/3.5G/4G USB Dongle
USB Sharing
- USB 2.0 for File Sharing
Antenna
- 2dBi Detachable Antenna x 3
- Reversed SMA Male Connector
WPS Button
- For WPS Connection
Wireless On/Off Button
- Enable /Disable Wireless Radio
Reset Button
- Reset Router Setting to Factory Default
LED Indication
- Status / 2.4GHz/5GHz/ USB1/USB2/ WAN / LAN1 ~ LAN4
Power Jack
- DC 12V/1.5A Switching Power Adapter
Wireless LAN
Częstotliwość:
2.4GHz Radio
- USA (FCC) 11 Channels: 2.412GHz~2.462GHz
- Europe (ETSI) 13 Channels :2.412GHz~2.472GHz
5GHz Radio
- USA (FCC) : 5180GHz~5240GHz 5745GHz~5805GHz
- Europe (ETSI) : 5180GHz~5240GHz
Czułość:
2.4G
- 802.11b 11Mbps ≦ -82dBm
- 802.11g 54Mbps ≦ -72dBm
- 802.11n HT20 MCS7 ≦ -70dBm
- 802.11n HT40 MCS7 ≦ -68dBm
5G
- 802.11a 11Mbps ≦ -72dBm
- 802.11n HT20 MCS7 ≦ -70dBm
- 802.11n HT40 MCS7 ≦ -68dBm
Transfer:
- 802.11n(Mbps)
- 5G(3T/3R)(MCS0~MCS23)
- 20 MHz BW(LGI):
195,175.5,156,130,117,104,78,65,58.5,52,39,26,19.5,13,6.5
- 40 MHz BW(LGI):
405,364.5,324,270,243,216,162,121.5,135,108,81,54,40.5,27,13.5
- 20 MHz BW(SGI):
216.7,195,173.3,144.4,130,115.6,86.7,72.2,65,57.8,43.3,28.9,21.7,
14.4,7.2
- 40 MHz BW(SGI):
450,405,360,300,270,240,180,150,135,120,90,60,45,30,15
- 2.4G(2T2R)(MCS0~MCS15)
- 20 MHz BW(LGI):
130,117,104,78,65,58.5,52,39,26,19.5,13,6.5
- 40 MHz BW(LGI):
270,243,216,162,121.5,135,108,81,54,40.5,27,13.5
- 20 MHz BW(SGI): 144.4,130,115.6,86.7,72.2,65,57.8,43.3,28.9,21.7,14.4,7.2
- 40 MHz BW(SGI):
300,270,240,180,150,135,120,90,60,45,30,15
- 802.11g/a(Mbps) 54, 48, 36, 24, 18, 12, 9 ,6
- 802.11b(Mbps) 11, 5.5, 2 ,1
Fukcje
Ethernet WAN
- PPPoE, DHCP client, Static IP, PPTP, L2TP
WAN Connection
- Auto-Reconnect, Dial-On-Demand, Manually
IPv6 support
- Dual Stack IPv6 support
One-to-Many NAT
- Virtual server, special application, DMZ
NAT Session
- Support NAT session up to 20000
SPI Firewall
- IP/Service filter, URL blocking, MAC control
DoS Protection
- DoS (Deny of Service) detection and protection
Storage/File Sharing
- AT16/FAT32, EXT2, NTFS (Read only), Samba server, FTP server
Routing Protocol
- Static route, dynamic route (RIP v1/v2)
Media server
- UPnP AV media server, iTunes server
Scheduling Download management
- FTP, HTTP, BitTorrent
Management
- SNMP, UPnP IGD, Syslog, DDNS
Administration
- Web-based UI, Remote Login, Backup/Restore setting
AirLive IPcam support
- IPCAM Plug-n-Play
VLAN
|
