CPU

• Supports 64-bit AMD® Athlon™ 64 , Sempron™ and Turion™ 64 processor (Socket 754)
• Supports up to 3700+ Athlon 64, or higher CPU

Chipset

•ATI® Radeon XPRESS 200 (RS482) Chipset
- HyperTransport™ connection to AMD K8 Athlon64 processor
- 8 or 16 bit control/address/data transfer both directions
- 800MHz "Double Data Rate" operation both direction
- Compliant with PCI Express 1.0a specifications (one x16 graphics interface, which can be divided into two smaller links for use by other devices)
- Graphic integrated

•ATI® SB400 Chipset
- Supports SATA controller up to 150MB/s with RAID 0 or RAID 1
- Integrated Hardware Sound Blaster/Direct Sound AC97 audio
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- ACPI & PC2001 compliant enhanced power management
- Supports USB2.0 up to 8 ports

Main Memory

• Supports four memory banks DDR 333/400, using two 184-pin DDR DIMMs.
• Supports a maximum memory size up to 2GB without ECC.
• Supports 2.5v DDR DRAM DIMM.

Slots

• One PCI Express x 16 slot. (supports PCI Express Bus specification v1.0a compliant)
• Three 32-bit v2.2 Master PCI bus slots (support 3.3v/5v PCI bus interface).

On-Board IDE / SATA

• An IDE controller on the ATI® SB400 chipset provides IDE HDD/CDROM with PIO, Bus
  Master and Ultra DMA 66/100/133 operation modes
- Can connect up to 4 IDE devices

• Serial ATA/150 controller integrated by ATI® SB400
- Up ot 150MB/s transfer rate
- Can connect up to 4 serial ATA devices
- Supports RAID 0 or RAID 1

Audio

•AC97 link controller integrated in ATI® SB400
•6 channels software audio codec RealTek ALC655
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.

LAN

•Realtek® 8100C or 8110S LAN chipset
- Integrated Fast Ethernet MAC and PHY in one chip
- Supports 10Mb/s, 100Mb/s and 8110S supports up to 1000Mb/s.
- Compliance with PCI v2.2
- Supports ACPI Power Management

IEEE1394

•VIA® 6307chipset
- Supports up to two 1394 ports. (Rear panel x1, pinheader x1)
- Transfer rate is up to 400Mbps

Internal I/O Connectors

- ATX 24-Pin power connector
- 4-pin ATX 12V power connector
- CPU / System FAN connectors
- CD-In connector
- SPDIF-Out connector
- Serial port header (COM2)
- IEEE 1394 connector
- IrDA infrared module header
- Chassis intrusion switch connector
- TV-Out connector
- Clear COMS Jumper
- 2 x USB 2.0 connector support additional 4 ports
- Front panel audio connector
- Front panel connector
- 1 x Floppy disk drive connector
- 4 x Serial ATA connectors
- 2 x ATA133 HD connectors

Back Panel I/O Ports

- 1 x Parallel
- 1 x PS/2 Keyboard
- 1 x PS/2 Mouse
- 1 x Serial Port (COM1)
- 1 x VGA Port
- 1 x Audio I/O (Line-in/Line-out/MIC)
- 4 x USB 2.0
- 1 x IEEE1394
- 1 x RJ45 LAN Jack

Dimension

• 24.4cm(L) x 24.4cm(W) Micro-ATX Form Factor
