CPU

• AMD® Athlon 64 X2, Athlon 64 and Sempron in the Socket AM2 package.
Please refer to CPU Support for compatible CPU; the above description is for reference only.

FSB

• HyperTransport supporting speed up to 800MHz (1600MT/s)

Chipset

• VIA® K8M800 and VT8237R Plus Chipset

Main Memory

• Supports Dual DDR2 533/667/800
- 2 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 2GB.

Slots

• One AGP 8x slot.
• Three PCI slots (support 3.3v/5v PCI bus interface).

Audio

• Chipset integrated by Realtek® ALC655
- 6-channel audio-out
- Compliant with AC97 v2.3 Spec

LAN

• Supports 10/100 Fast Ethernet by Realtek RTL8201CL

Internal I/O Connectors

- ATX 24-pin power connector
 - 4-pin ATX 12V power connector
 - CPU / System FAN connectors
 - CD-in connector
 - Serial port connector
 - 1 x Floppy disk drive connector
 - 2 x SATA connectors
 - 1 x ATA133 HD connector
 - 2 x USB 2.0 connector support additional 4 ports
 - Front panel connector
 - Front panel audio connector
 - Chassis intrusion switch connector
 - Clear CMOS Jumper

Back Panel I/O Ports

- 1 x Parallel
 - 1 x PS/2 Keyboard
 - 1 x PS/2 Mouse
 - 1 x Serial port
 - 1 x VGA port
 - 1 x 3-in-1 Audio I/O port
 - 4 x USB 2.0
 - 1 x RJ45 LAN Jack
