MSI Socket LGA 775 Micro ATX Motherboard

Model: MS-7046

• Motherboard Specifications:


• CPU
• Supports Intel Pentium 4 Prescott LGA775 processors in LGA775 package.
• Supports up to Pentium 4 3XX, 5XX sequence processor or higher speed.
• Supports Intel Hyper-Threading Technology.


• Chipset
• Intel 915P chipset
• Supports FSB 533/800MHz.
• Supports DDR 400/333 memory interface.


• Intel ICH6 chipset
• Hi-Speed USB (USB2.0) controller, 480Mb/sec, up to 8 ports.
• 4 Serial ATA ports with transfer rate up to 150 Mbytes/sec.
• 1 channel Ultra ATA 100 bus Master IDE controller.
• PCI Master v2.3, I/O APIC.
• ACPI 2.0 Compliant.


• Main Memory
• Supports four DDR1 SDRAM memory modules.
• Supports up to 4GB memory size.
• Supports Dual channel DDR1.


• Slots
• One PCI Express x16 slot (supports PCI Express Bus specification v1.0a compliant).
• Three 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface).
• The second PCI slot (PCI2, in blue color) supports 2 master devices.


• On-Board IDE
• One Ultra DMA 66/100 IDE controllers integrated in ICH6.
• Supports PIO, Bus Master operation modes.
• Can connect up to Two Ultra ATA drives.


• Serial ATA 150 controller integrated in ICH6.
• Up to 150MB/sec transfer speed.
• Can connect up to four Serial ATA devices.


• On-Board Peripherals
• 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
• 1 serial port
• 1 parallel port supports SPP/EPP/ECP mode
• 8 USB 2.0 / 1.1 ports (Rear*4 / Front*4)
• 1 RJ45 connector
• 1 Rear 1394 port (6 Pins) / 1 Front 1394 port (4/6 Pins)
• 1 Coaxial SPDIF-Out / SPDIF-In
• 1 MIC-In
• 4 Line-Out1-3Getting Started


• LAN
• VIA VT6105L LAN Controller
• 10/100 IEEE 802.3/802.3u 10Base-T, 100Base-T compliant.


• IEEE 1394
• VIA VT6307 PCI 1394a Integrated Host Controller


• Audio
• Azalia link controller integrated in Intel ICH6 chipset.
• 8-channel audio codec CMedia CMI9880L.


• BIOS
• The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheraldevices and expansion cards of the board automatically.
• The mainboard provides a Desktop Management Interface (DMI) function whichrecords your mainboard specifications.


• Dimension
• M-ATX Form Factor: 24.38 cm (L) x 24.38 cm (W)
