CPU

• AMD® Athlon 64 X2, Athlon 64 and Sempron in the Socket AM2 package.

Hyper Transport Bus

• HyperTransport 1.0/2.0 supporting speed up to 1GHz (2000MT/s)

Chipset

• NVIDIA® MCP61 (P/S/V)

Main Memory

• Supports Dual Channel DDR2 533/667/800
- 2 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 8GB.

Slots

• One PCI Express x16 slot. (K9N6PGM-FI/F)
• One PCI Express x1 slot.
• Two PCI slots (support 3.3v/5v PCI bus interface).

On-Board IDE

• One IDE port by NVIDIA® MCP61 (P/S/V)
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices

On-Board SATA

• Two SATA II ports by NVIDIA® MCP61 (P/S/V)
- Supports storage and data transfers at up to 3Gb/s

RAID Function

- SATA II 1~2 supports RAID 0, 1 mode by NVIDIA®MCP61 (P/S/V)

Audio

• Chipset integrated by Realtek® ALC861/883/888
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Supports 10/100 Fast Ethernet by Realtek 8201CL (K9N6SGM-V, K9N6VGM-V)
• Supports 10/100/1000 Fast Ethernet by Realtek 8211BL-GR (K9N6PGM-FI/F)

IEEE1394 / FireWire

• Chipset integrated by VIA® VT6308P
- Transfer rate is up to 400Mbps

Internal I/O Connectors

- ATX 24-pin power connector
- 4-pin ATX 12V power connector
- CPU / System FAN connectors
- CD-in connector
- 1 x Floppy disk drive connector
- 2 x SATA II connectors
- 1 x ATA133 connectors
- 2 x USB 2.0 connector support additional 4 ports
- 1 x IEEE1394 connector support additional 1 ports
- SPDIF-Out connector
- Front panel connector
- Front panel audio connector
- Chassis intrusion switch connector
- Clear CMOS Jumper

Back Panel I/O Ports

- 1 x PS/2 Keyboard
- 1 x Parallel port
- 1 x Serial port
- 1 x PS/2 Mouse
- 1 x VGA port
- 1 x IEEE1394 port
- 1 x 6 in 1 audio jack
- 4 x USB 2.0
- 1 x RJ45 LAN Jack
