AMD® Phenom/Athlon/Sempron CPU.
• Support socket AM3 CPU. (65W only)
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Hyper Transport Bus

• HyperTransport 3.0 supporting speed up to 5200MT/s
- AM2 CPU supports HyperTransport 1.0/2.0
- AM2+ CPU supports HyperTransport 3.0

Chipset

• AMD® 780V and SB700 Chipset

Main Memory

• Supports Dual DDR2 533/667/800/1066 (only for AM2+)
- 2 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 4GB.

Slots

• 1 PCI Express x16 slot (PCI Express Bus SPEC V2.0 compliant)
• 1 PCI Express x1 slot
• 2 PCI slots, support 3.3V/ 5V PCI bus Interface.

On-Board IDE

• One IDE port by AMD® SB700
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices

On-Board SATA

• 4 SATA II (1~4) ports by AMD® SB700
- Supports storage and data transfers at up to 3Gb/s


RAID Function

- SATA II 1~4 support RAID 0, 1, 0+1 and JBOD mode by AMD® SB700

MSI Reminds You... • The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.

Audio

• Chipset integrated by Realtek® ALC888/ALC662
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Supports 10/ 100 Fast Ethernet by Realtek 8101E
• Or Supports PCIE LAN 10/100/1000 Fast Ethernet by Realtek 8111B/ 8111C

IEEE1394 / FireWire

• Chipset integrated by JMicron® 381
- Transfer rate is up to 400Mbps

Internal I/O Connectors

- ATX 24-pin power connector
- ATX 4-pin 12V CPU power connector
- CPU / System x 1 FAN connectors
- CD-in connector
- Front panel audio connector
- Front panel connector
- Chassis intrusion switch connector
- 3 x USB 2.0 connector support additional 6 ports
- 1 x Floppy disk drive connector
- 4 x Serial ATA II connectors
- 1 x ATA133 IDE connector
- Clear CMOS jumper
- 1 x SPDIF-out header
- 1 x IEEE1394 connector support additional 1 port (optional)
- 1 x TPM module header (optional)

MSI Reminds You... • The floppy disk cable will be optional.

Back Panel I/O Ports

- 1 x PS/2 keyboard
- 1 x PS/2 mouse

- 1 x Parallel port
- 1 x Serial port
- 1 x 6 in 1 audio jack
- 4 x USB 2.0 ports
- 1 x RJ45 LAN jack
- 1 x Graphic Card port
- 1 x IEEE1394 port (optional)

Dimension

• 24.4cm(L) x 21.5cm(W) M-ATX Form Factor

Mounting

• 6 mounting holes.
