CPU

• Supports 64-bit AMDR® Athlon™ 64, Sempron™ and Turion™ 64 processor (Socket 754)
• Athlon 64 2800+ ~ 3700+, Sempron 3400+
• Supports new E6 version CPU
•Please refer to CPU Support for compatible CPU; the above description is for reference only.

Chipset

•VIA® K8M800 Chipset
- HyperTransport™ connection to AMD® Athlon™ 64 processor
- 8 or 16 bit control/address/data transfer both directions
- 800/600/400/200MHz "Double Data Rate" operation both direction
- AGP v3.0 compliant with 8x transfer mode
- Graphic integrated

•VIA® VT8237R Chipset
- Integrated Hardware Sound Blaster/Direct Sound AC97 audio
- Ultra DMA 66/100/133 master mode PCI EIDE controller
- ACPI & PC2001 compliant enhanced power management
- Supports 2 Serial ATA ports
- Supports 8 USB2.0 ports
- Supports SATA RAID 0 or 1

Main Memory

• Supports DDR266/333/400 DDR DRAM for two 184-pin DDR DIMMs.
• Supports a maximum memory of 2GB.

Slots

• One AGP 8x/4x slot
- AGP 3.0 specification compliant
• Three 32-bit Master PCI bus slots (support 3.3v/5v PCI bus interface).

On-Board IDE/SATA

• An IDE controller on the VIA® VT8237R chipset provides IDE HDD/CDROM with PIO, Bus
Master and Ultra DMA 66/100/133 operation modes
- Can connect up to four Ultra ATA drives.

• Serial ATA/150 controller integrated by VT8237R
- Up ot 1.5Gb/s transfer rate
- Can connect up to 2 serial ATA devices
- Supports SATA RAID 0 or 1

Audio

• 6 channels software audio codec VIA VT1617A
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.

LAN

•VIA® VT6103L 10/100Mb/s PHY
- Compliant with PCI v2.2 and PC99 standard.
- Supports ACPI Power Management.

Internal I/O Connectors

- ATX 20-Pin power connector
- 4-pin ATX 12V power connector
- CPU / System FAN connectors
- CD-in connector
- Aux Line-in connector
- IrDA infrared module header
- Clear CMOS jumper
- S/PDIF Out connector
- Serial port connector (COM2)
- 2 x USB 2.0 connector support additional 4 ports
- Front panel audio connector
- Front panel connector
- 1 x Floppy disk drive connector
- 2 x Serial ATA connectors
- 2 x ATA133 HD connectors

Back Panel I/O Ports

- 1 x PS/2 Keyboard
- 1 x PS/2 Mouse
- 1 x Parallel
- 1 x Serial port (COM 1)
- 1 x VGA
- 1 x Audio I/O (Line-in/Line-out/MIC)
- 4 x USB 2.0
- 1 x RJ45 LAN Jack

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and
expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your
motherboard specifications.

Dimension

• 24.4cm(L) x 21.5cm(W) Micro-ATX Form Factor
