NOWA PŁYTA GŁÓWNA

MSI 945GCM478

MS-7536

socket 478

MSI 945GCM478 MS-7536 PCIE DDR2 SATA HD AUDIO

CPU

• Supports Intel® P4 Northwood/Prescott/Celeron processors.

• Supports FSB 533/ 800MHz.

Please refer to CPU Support for compatible CPU; the above description is for reference only.

Chipset

• Intel® 945GC Chipset

- Integrated Intel Graphics Media Accelerator 950

- Max. resolution: 2048x1536 @75Hz, Vertical: 85Hz@ up to 1920x1440

• Intel® ICH7 Chipset

- Hi-Speed USB (USB2.0) controller, 480Mb/sec, up to 8 ports.

- 4 SATAII ports with transfer rate up to 3Gb/s.

- 1 channel Ultra ATA 100 bus master IDE controller.

- PCI Master v2.3, I/O APIC.

Main Memory

• Supports two unbuffered DIMM of 1.8 Volt DDR2 DRAM

• Supports dual channel DDR2 memory architecture.

• Supports DDR2 533/667 memory interface. (4GB Max)

Slots

• One PCI Express x16 slot.

• Two 32-bit v2.3 master PCI bus slots. (support 3.3v/5v PCI bus interface)

On-Board IDE/SATA

• One Ultra DMA 66/100 IDE controllers integrated in ICH7

- Supports PIO, Bus Master operation modes.

- Can connect up to two Ultra ATA drives.

• SATAII controller integrated in ICH7

- Up to 3Gb/s transfer speed.

- Can connect up to four SATAII devices.

Audio

• Chip integrated by Realtek® ALC888

- Flexible 7.1-channel audio with jack sensing

- Compliant with Azalia 1.0 Spec

LAN

• Supports 10 / 100 Mb/s Fast Ethernet by Realtek RTL8101E.

• Supports 10 / 100 /1000 Mb/s Fast Ethernet by Realtek RTL8111C.

- Supports ACPI Power Management.

Internal I/O Connectors

- ATX 24-Pin power connector

- 4-pin ATX 12V power connector

- 1 x CPU / System x 2 FAN connectors

- CD-in connector

- Front panel audio connector

- 2 x Front panel connectors

- 2 x USB 2.0 connector support additional 4 ports

- 1 x Floppy disk drive connector

- 4 x Serial ATAII connectors

- 1 x ATA100 connector

- 1 x SPDIF-out connector

- Chassis intrusion switch connector

- Clear CMOS jumper

MSI Reminds You...

• The floppy disk cable will be optional.

Back Panel I/O Ports

- 1 x Parallel port

- 1 x Serial port (COM 1)

- 1 x Graphics Card port

- 1 x PS/2 keyboard

- 1 x PS/2 mouse

- 1 x 6 in 1 audio jack

- 4 x USB 2.0 ports

- 1 x RJ45 LAN jack

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.

• The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.

Dimension

• 24.5cm(L) x 20.0cm(W) Micro-ATX Form Factor

Mounting

• 6 mounting holes.

MASKOWNICA W ZESTAWIE
