CPU • 64bit AMD® FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU. Please refer to CPU Support for compatible CPU; the above description is for reference only. Hyper Transport Bus
• HyperTransport 3.0 supporting speed up to 5200MT/s Chipset
• AMD® 880G and SB850 Chipset
|
 |
Main Memory • Supports two unbuffered DIMM of 1.5 Volt DDR3 800/[zasłonięte]/1333 DRAM, 16GB Max
|
 |
Slots
• 1 PCI Express x16 slot with x16 operation (PCI Express Bus SPEC V2.0 compliant) • 1 PCI EXpress x1 slot • 1 PCI slot, support 3.3V/ 5V PCI bus Interface.
|
 |
On-Board SATA • 6 SATA 6Gb/s (1~6) ports by AMD® SB850 - Supports storage and data transfers at up to 6Gb/s RAID Function - SATA 1~6 support RAID 0, 1, 10 or JBOD mode by AMD® SB850
MSI Reminds You... • The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk. |
|
 |
Audio
• Chipset integrated by Realtek® ALC887 - Flexible 7.1-channel audio with jack sensing - Compliant with Azalia 1.0 Spec
|
 |
LAN • Realtek PCI-E GbLAN controller RTL8111E - Supports 10Mb/s, 100Mb/s and 1000Mb/s - Compliance with PCI-Express Bus specification v1.0a
|
 |
Internal I/O Connectors
- 1 x ATX 24-pin power connector - 1 x ATX 4-pin 12V CPU power connector - CPU x 1 / System x 1 FAN connectors - 1 x Front panel audio connector - 1 x Front panel connector - 1 x Chassis intrusion switch connector - 3 x USB 2.0 connectors - 6 x Serial ATA III connectors - 1 x Serial port connector - 1 x Clear CMOS jumper - 1 x SPDIF-out connector - 1 x TPM module connector
|
 |
Back Panel I/O Ports
- 1 x PS/2 keyboard or mouse port - 6 x USB 2.0 ports - 1 x Graphic Card port - 1 x DVI-D port - 1 x HDMI port - 1 x RJ45 LAN jack - 1 x 3 in 1 audio jack
|
 |
Dimension
• 24.4cm(L) x 20.5cm(W) Micro-ATX Form Factor
Mounting
• 6 mounting holes.
|
