CPU

• 64bit AMD® Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU.
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Hyper Transport Bus

• HyperTransport 3.0 supporting speed up to 5200MT/s

Chipset

• AMD® 770 and SB710 Chipset

Main Memory

• Supports four unbuffered DIMM of 1.5 Volt DDR3 800/[zasłonięte]/1333/1600* (OC) DRAM, 16GB Max

Slots

• 1 PCI Express 2.0 slot with x16 operation (PCI Express Bus SPEC V2.0 compliant)
• 1 PCI Express 2.0 slot with x4 operation (PCI Express Bus SPEC V2.0 compliant)
• 1 PCI EXpress x1 slot
• 3 PCI slots, support 3.3V/ 5V PCI bus Interface.

On-Board IDE

• One IDE port by AMD® SB710
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices

On-Board SATA

• 6 SATA II (1~6) ports by AMD® SB710
- Supports storage and data transfers at up to 3Gb/s

RAID Function

- SATA II 1~6 support RAID 0, 1, 10 or JBOD mode by AMD® SB710

MSI Reminds You... • The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.

Audio

• Chipset integrated by VIA® VT1828S
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Atheros PCI-E GbLAN controller AR8131M
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
- Compliance with PCI-Express Bus specification v1.0a

Internal I/O Connectors

- 1 x ATX 24-pin power connector
- 1 x ATX 4-pin 12V CPU power connector
- CPU x 1 / System x 2 FAN connectors
- 1 x Front panel audio connector
- 1 x Front panel connector
- 1 x Chassis intrusion switch connector
- 3 x USB 2.0 connectors
- 6 x Serial ATA II connectors
- 1 x ATA133 HD connector
- 1 x OC Switch
- 1 x Clear CMOS jumper
- 1 x SPDIF-out  connector
- 1 x TPM module connector

Dimension

• 30.5cm(L) x 21.0cm(W) ATX Form Factor

Mounting

• 6 mounting holes.
