Kontroler Raid PERC 4e/Di 256MB DDR2

Zestaw nie zawiera baterii oraz kabli SCSI.

The RAID controller recognizes and uses drive arrays created on existing PERC 3SCDCQC and PERC 4SCDC RAID controllers without risking data loss, corruption, redundancy or configuration loss. Similarly, the arrays created on the RAID controller can be transferred to other PERC 4 controllers.

Specyfikacja:

Processor - Intel® IOP332 I/O processor with Intel XScale Technology
Bus type - PCI Express Rev. 1.0a
PCI Express controller - Intel i303
Bus data transfer rate - Up to 4 GB/sec
Cache memory size - 256 MB (DDR2)
Cache function - Write-back, Write-through, Adaptive read-ahead, Non read-ahead, Read-ahead
Firmware - 4 MB × 16 flash ROM
Nonvolatile random access memory (RAM) - 32 KB × 8 for storing RAID configuration
SCSI data transfer rate - Up to 320 MB/sec per channel
SCSI bus - LVD
SCSI termination - Active
Termination disable - Automatic through cable and device detection
Devices per SCSI channel - Up to 15 wide or seven narrow SCSI devices
SCSI device types - Synchronous or asynchronous
RAID levels supported - 0, 1, 5, 10, and 50
Multiple logical drives/arrays per controller - Up to 40 logical drives per controller
Online capacity expansion - Yes
Dedicated and pool hot spare - Yes
Flashable firmware - Yes
Hot swap devices supported - Yes
Non-disk devices supported - Yes
Mixed capacity hard drives - Yes



Array Performance Features:

Host data transfer rate - 2-4 GB/sec, depending on the system
Drive data transfer rate - Up to 320 MB/sec
Stripe sizes - 8 KB, 16 KB, 32 KB, 64 KB, or 128 KB
Maximum number of concurrent commands - 189
Support for multiple initiators - Yes


Więcej informacji na stronie producenta: http://support.dell.com/support/edocs/storage/p62517/en/chapterb.htm
