PCI Bus PCI-Express x4 lanes
PCI Modes Bus Master DMA
RAID Levels RAID 0, 1, 1E and 10E
PCI Data Burst Transfer Rate:
250 MB/s per lane half duplex
500 MB/s per lane full duplex
1,000 MB/s 4-lane half duplex
SAS Bandwidth Half Duplex Single lane - 300 MB/s
Wide Port (2 lanes) - 600 MB/s
Wide Port (4 lanes) - 1200 MB/s
Full Duplex Single SAS Lane - 600 MB/s
Wide Port (2 lanes) -1200 MB/s
Wide Port (4 lanes) - 2400 MB/s
PCI Card Type 3.3 volt add-in card
PCI Voltage 12 V ± 10%
PCI Power 7.5 Watts
Bracket Full height and Low-profile
Certification Level PCI-Express 1.0a
IO Bus Four 3 Gb/s SAS/SATA ports
SAS Processor LSISAS1064E
Internal Connectors Four- SATA x1 connectors
External Connectors None
Maximum Number of SCSI Devices 122
LED Indicators On-board activity and fault LEDs
Integrated Mirroring Integrated Mirroring option available
Temperature Operating 0° to 60° C
Storage -45° to +105° C
Relative Humidity Operating 5 to 90% non-condensing
Storage 5 to 90% non-condensing
MTBF >200,000 hours
