KONTROLER FC FIBRE CHANNEL 4Gbit QLE2460

na złączu PCI-e profil krótki

>>SPECYFIKACJA<<

Bus interface
••PCI Express x4
Memory
••1MB SRAM, 1MB flash (SPI), and
2KB NVRAM (SPI)
Hardware platforms1
••IA32 (x86), IA64, IEM64T, AMD Opteron™ 64, Sun™
SPARC®, Apple® G5 (Xserve® and Power Mac®)
Compliance
••PCI Express Base Specification, revision 1.0a, PCI
Express Card Electromechanical Specification
rev. 1.0, PCI Bus Power Management Interface
Specification revision 1.1
Fibre Channel Specifications
Data rate
••4/2/1Gbps auto-negotiation (4.2480/ 2.1240/
1.0625Gbps)
Performance
••150,000 IOPS
Topology
••Point-to-point (N_Port), arbitrated loop (NL_Port),
switched fabric (N_Port)
Logins
••Support for F_Port and FL_Port login: 2,048
concurrent logins and 2,048 active exchanges
Class of service
••Class 2 and 3
Protocols
••FCP (SCSI-FCP), FC-TAPE (FCP-2)
Compliance
••SCSI-3 Fibre Channel Protocol (SCSI-FCP), Fibre
Channel Physical and Signaling Interface (FC-PH),
Fibre Channel 2nd Generation (FC-PH-2), Third
Generation Fibre Channel Physical and Signaling
Interface (FC-PH-3), Fibre Channel-Arbitrated Loop
(FC-AL-2), Fibre Channel Fabric Loop Attachment
Technical Report (FC-FLA), Fibre Channel-Private
