Model
|
B75 PRO3
|
|
Gniazdo procesora
|
LGA1155
|
|
Typ procesora
|
Intel Core i3 i5 i7
|
|
Zintegrowany procesor
|
nie
|
|
Producent chipsetu
|
Intel
|
|
Typ chipsetu
|
- Intel® B75
- Supports Intel® Small Business Advantage
- Supports Intel® Rapid Start Technology and Smart Connect Technology
|
|
Rodzaj pamięci
|
DDR3
|
|
Liczba gniazd DDR3
|
4 szt.
|
|
Częstotliwość szyny pamięci
|
1066 MHz 1333 MHz 1600 MHz
|
|
Max. wielkość pamięci
|
32 GB
|
|
Złącza PCI
|
2 szt.
|
|
Złącza PCI-E 16x ver. 3.0
|
1 szt.
|
|
Złącza PCI-E 16x ver. 2.0
|
1 szt.
|
|
Złącza PCI-E 8x
|
Brak
|
|
Złącza PCI-E 4x
|
Brak
|
|
Złącza PCI-E 1x
|
1 szt.
|
|
Złącze AGP
|
Nie
|
|
Maksymalna ilość urządzeń SATA
|
8
|
|
Maksymalna ilość urządzeń ATA
|
0
|
|
RAID
|
nie
|
|
Szczegółowe dane o interfejsach dysków/napędów
|
- 1 x SATA3 6.0 Gb/s connector by Intel® B75, supports NCQ, AHCI and Hot Plug functions
- 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug functions
- 5 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and Hot Plug functions
|
|
Zintegrowana karta graficzna
|
nie
|
|
Typ zintegrowanej karty graficznej
|
- Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video 2.0, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics 2500/4000
- Pixel Shader 5.0, DirectX 11 with Intel® 22nm CPU. Pixel Shader 4.1, DirectX 10.1 with Intel® Sandy Bridge CPU.
- Max. shared memory 1760MB
- Multi VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI 1.4a Technology with max. resolution up to 1920x1200 @ 60Hz
- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @ 75Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required)
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI and HDMI ports
|
|
Karta dźwiękowa
|
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
- Supports THX TruStudio™
|
|
Interfejs sieciowy
|
10/100/1000 Mbit/s
|
|
Interfejs sieciowy
|
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE
|
|
Złącza USB na tylnym panelu
|
6
|
|
Złącza USB do wyprowadzenia z płyty
|
5
|
|
Liczba portów USB 3.0
|
4
|
|
FireWire (IEEE 1394)
|
nie
|
|
Port COM
|
Tak
|
|
Port LPT
|
Nie
|
|
Interfejsy na tylnym panelu
|
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
|
|
Złącza dostępne na płycie
|
- 5 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and Hot Plug functions
- 3 x SATA3 6.0 Gb/s connectors
- 1 x IR header
- 1 x CIR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x Power LED header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 1 x USB 3.0 header (supports 2 USB 3.0 ports)
|
|
Funkcje specjalne
|
- ASRock Extreme Tuning Utility (AXTU)
- ASRock Instant Boot
- ASRock Instant Flash
- ASRock APP Charger
- ASRock SmartView
- ASRock XFast USB
- ASRock XFast LAN
- ASRock XFast RAM
- ASRock Crashless BIOS
- ASRock On/Off Play Technology
- ASRock OMG (Online Management Guard)
- ASRock Internet Flash
- Hybrid Booster:
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Combo Cooler Option (C.C.O.)
- Good Night LED
|
|
Bios
|
- 64Mb AMI UEFI Legal BIOS with GUI support
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage Multi-adjustment
|
|
Format płyty
|
ATX
|
|
Wymiary
|
30.5 cm x 19.3 cm
|
|
Certyfikaty
|
- FCC, CE, WHQL
- ErP/EuP Ready
|
