| CPU |
- Support for Socket AM3/ AM2+/ AM2 processors: AMD Phenom™FX processor/ AMD Phenom™ processor/ AMD Athlon™ 64 FX processor/AMD Athlon™ 64 X2 Dual-Core processor/AMD Athlon™ 64 processor/AMD Sempron™ processor
(Note) If you install AMD AM3/AM2+ CPU on AM2 motherbord, the system bus speed will downgrade from HT3.0(5200MHz) to HT1.0(2000 MT/s) spec; however, the frequency of AM3/AM2+ CPU will not be impacted. Please refer "CPU Support List" for more information.
|
| Hyper Transport Bus |
- 2000 MT/s
|
| Chipset |
- North Bridge: AMD 740G
- South Bridge: AMD SB700
|
| Memory |
- 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory (Note 1)
- Dual channel memory architecture
- Support for DDR2 800/667 MHz memory modules
|
| Onboard Graphics |
- Integrated in the North Bridge
|
| Audio |
- Realtek ALC888 codec
- High Definition Audio
- 2/4/5.1/7.1-channel (Note 2)
- Support for S/PDIF Out
- Support for CD In
|
| LAN |
- Realtek 8111C chip (10/100/1000 Mbit)
|
| Expansion Slots |
- 1 x PCI Express x16 slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
|
| Storage Interface |
South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1 and RAID 10
iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
|
| USB |
Integrated in the South Bridge
- Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers)
|
| Internal I/O Connectors |
- 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 1 x floppy disk drive connector
- 1 x IDE connector
- 6 x SATA 3Gb/s connectors
- 1 x CPU fan header
- 1 x system fan header
- 1 x front panel header
- 1 x front panel audio header
- 1 x CD In connector
- 1 x S/PDIF Out header
- 4 x USB 2.0/1.1 headers
- 1 x Serial port header
- 1 x Trusted Platform Module (TPM) header
- 1 x chassis intrusion header
- 1 x power LED header
|
| Back Panel Connectors |
- 1 x PS/2 keyboard port
- 1 x Parallel port
- 1 x D-Sub port
- 1 x DVI-D port (Note 3)
- 1 x HDMI port
- 1 x coaxial S/PDIF Out connector
- 4 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 3 x audio jacks (Line In/Line Out/Microphone)
|
| I/O Controller |
- ITE IT8718 chip
|
| H/W Monitoring |
System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control (Note 4)
|
| BIOS |
- 1 x 8 Mbit flash
- Use of licensed AWARD BIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
|
| Unique Features |
- Support for @BIOS
- Support for Download Center
- Support for Q-Flash
- Support for EasyTune (Note 5)
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for Virtual Dual BIOS
|
| Bundle Software |
- Norton Internet Security (OEM version)
|
| Operating System |
- Support for Microsoft® Windows Vista/ XP
|
| Form Factor |
- Micro ATX Form Factor; 24.4cm x 23.4cm
|
| Remark |
- Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
|
| Note |
(Note 1) Due to Windows® XP 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) To configure 7.1-channel audio, you need connect with the port of HD Audio standard via front panel and enable the multi-channel audio feature through the audio driver.
(Note 3) The DVI-D port does not support D-Sub connection by adapter.
(Note 4) Whether the CPU/System fan speed control function is supported will depend on the CPU you install.
(Note 5) Available functions in Easytune may differ by motherboard model. |
