| FUNCTIONAL SPECIFICATIONS |
| Formatted storage capacity |
73.5 GB |
| PHYSICAL SPECIFICATIONS |
| Track capacity (formatted) |
285 KB ~ 360 KB bytes |
| Cylinders |
27,100 |
| Sectors per track |
558 ~ 705 |
| FUNCTIONAL SPECIFICATIONS |
| Seek time (track to track) |
Read 0.3 / Write 0.5 ms. typ. |
| Seek time (average) |
3.3/3.8 ms. typ. (read/write) |
| Seek time (full track) |
8.00/9.0 ms. typ. (read/write) |
| Average latency time |
2.00 ms. |
| Rotational speed |
15,000 RPM |
| Interface |
SCA-2 (ULTRA 320) |
| Data Buffer Size |
8 MB |
| Recording code |
32/34 MATCHED NPV 2 |
| Head positioning method |
ROTARY VCM |
| Spindle start time |
30 seconds typical |
| Spindle stop time |
30 seconds typical |
| PHYSICAL SPECIFICATIONS |
| Power requirement Spin up |
33.5W max. |
| Power requirement Idle (ready) |
11.74 W typ. |
| Form Factor |
3.5-inch x 1-inch high |
| Mounting screws |
6#32UNC |
| Height |
25.4 mm |
| Width |
101.6 mm |
| Depth |
146.0 mm |
| Weight |
0.80 kg |
| Ambient temperature (operating) |
5 to 55 degrees C |
| Ambient temperature (non-operating) |
-10 to 70 degrees C |
| Maximum DE surface temperature (operating) |
60 max deg. C |
| Gradient |
15 degrees C per hour |
| Relative humidity (operating) |
5 to 95 % RH (non-condensing) |
| Relative humidity (non-operating) |
5 to 95 % RH (non-condensing) |
| Maximum wet bulb |
29 degrees C (non-condensing) |
| Vibration (operating) |
0.3mm (5 to 20 Hz)/ 1.0G (20 to 300 Hz) |
| Vibration (non-operating) |
3.1mm (5 to 20 Hz)/ 5.0G (20 to 300Hz) |
| Shock (operating) |
65G Max (2ms) |
| Shock (non-operating) |
200G Max (2ms) |
| Altitude (operating) |
3,000 metres |
| Altitude (non-operating) |
12,000 metres |
| Acoustic noise (at 1 metre idle) |
3.6 bels |
