DFI HYBRID P45-ION-T2A2 ATOM230 DDR2 SKLEP FV

11-07-2012, 19:05
Aukcja w czasie sprawdzania była zakończona.

Cena kup teraz: 849 zł

Użytkownik sklepk-tech

numer aukcji: 2434384935

Miejscowość Poznań

Wyświetleń: 121

Koniec: 04-07-2012 02:11:16

Dodatkowe informacje:
Stan: Nowy
Standard płyty: ATX
Rodzaj pamięci: DDR2,

Przedmiotem aukcji sa nowe plyty glowne
DFI HYBRID P45-ION-T2A2

wersja box - komplet
12 miesiacy gwarancji od momentu wysylki
paragon,fvat dla firm

wiecej na temat plyty
http://www.purepc.pl/sprzet_pc/plyty_glowne/dfi_hb_p45_ion_t2a2_czyli_ion_i_p45_w_jednym

INTEL Platform

Processor

LGA 775 socket for:
- Intel® Core™2 Quad and Intel® Core™2 Duo

Supports Intel Enhanced Memory 64 Technology (EMT64T)

Supports Enhanced Intel SpeedStep Technology (EIST)

Supports Intel Hyper-Threading Technology

FSB

1333/1066/800MHz

Chipset

Intel® chipset
- Northbridge:
Intel® P45 Express chipset
Intel® Fast Memory Access technology
- Southbridge:
Intel® ICH10R

System Memory

Four 240-pin DDR2 DIMM sockets

Supports DDR2 1200(O.C.)/1066/800/667 MHz

Delivers up to 12.8Gb/s bandwidth

Supports dual channel (128-bit wide) memory interface

Supports non-ECC unbuffered DIMMs

Supports up to 16GB system memory Windows® 32-bit operating system is unable to accurately detect more than 4GB system memory. Therefore, if you are using this operating system, we strongly recommend that you install a less than 3GB system memory.

Expansion Slots

1 PCI Express (Gen 2) x16 slot

1 PCI Express x1 slot

1 PCI slot

PCIE Graphics Card QVL for P45 platform Hybrid mode
http://dfics.dfi.com.tw/dfi_cs/ABS_Profile/HB_VGA_support_list.pdf

BIOS

Award BIOS

8Mbit SPI flash BIOS

CMOS Reloaded

LAN

Realtek RTL8111DL PCIE Gigabit LAN controller

Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX) and 802.3ab (1000BASE-T) standards

Audio

Realtek ALC885 High Definition audio CODEC

8-channel audio output

DAC SNR/ADC SNR of 106dB/101dB

Full-rate lossless content protection technology

Optical S/PDIF-out and coaxial RCA S/PDIF-out interfaces

Serial ATA

Supports up to 6 SATA devices

SATA speed up to 3Gb/s

Intel Matrix Storage technology

Supports RAID 0, RAID 1, RAID 0+1 and RAID 5

Rear Panel I/O

6 USB 2.0/1.1 ports - 2 ports exclusively for Intel platform; the other 4 ports shared by both Intel and NVIDIA platforms.

1 optical S/PDIF-out port - Shared by both Intel and NVIDIA platforms

1 coaxial RCA S/PDIF-out port - Shared by both Intel and NVIDIA platforms

1 DVI-I input port and 1 DVI-I output port a. Connect a DVI cable from the PCIE graphics card to the DVI-I input port and then; b. Plug the monitor’s cable to the DVI-I output port

1 RJ45 LAN port

Line-in, line-out (front R/L) and mic-in jacks - Shared by both Intel and NVIDIA platforms

IDE

JMicron JMB368 PCI Express to PATA host controller

Supports up to 2 UltraDMA 100Mbps IDE devices

Internal I/O

1 10-pin connector for 2 additional external USB 2.0 ports

1 5-pin connector for 1 front panel USB (shared with NVIDIA platform)

1 front audio connector (shared with NVIDIA platform)

1 S/PDIF connector

6 Serial ATA connectors

1 40-pin IDE connector

1 24-pin ATX power connector

1 8-pin 12V power connector

1 front panel connector (shared with NVIDIA platform)

1 Intel CPU fan connector

2 Intel system fan connectors

1 download flash BIOS connector

Power Management

ACPI and OS Directed Power Management

ACPI STR (Suspend to RAM) function

Wake-On-USB Keyboard

Wake-On-LAN

RTC timer to power-on the system

AC power failure recovery

Hardware Mointor

Monitors CPU/system/Northbridge temperature and overheat alarm

Monitors Vcore/Vdimm/Vnb/VCC5/12V/V5sb/Vbat voltages

Monitors the speed of the cooling fans

CPU Overheat Protection function monitors CPU temperature and fan during system boot-up - automatic shutdown upon system overheat
