Standards
•
USB 2.0*
IEEE 802.11g
IEEE 802.11b
Bus Type
USB 2.0
Wireless Signal Rates** With Automatic Fallback
54Mbps
48Mbps
36Mbps
24Mbps
18Mbps
12Mbps
11Mbps
9Mbps
6Mbps
5.5Mbps
2Mbps
1Mbps
Security
64/128-bit WEP
WPA—Wi-Fi Protected Access
Media Access Control
CSMA/CA with ACK
Wireless Frequency Range
2.4GHz to 2.462GHz
Wireless Signal Range**
Indoors: Up to 328 ft (100 meters)
Outdoors: Up to 1312 ft (400 meters)
Modulation Technology
Orthogonal Frequency Division Multiplexing (OFDM)
Complementary Code Keying (CCK)
Receiver Sensitivity**
54Mbps OFDM
48Mbps OFDM
36Mbps OFDM
24Mbps OFDM
18Mbps OFDM
12Mbps OFDM
11Mbps CCK
9Mbps OFDM
6Mbps OFDM
5.5Mbps CCK
2Mbps QPSK
1Mbps BPSK
Transmitter Output Power
14Bm ± 2dB
Antenna Type
Omni Directional
Temperature
Operating: 32°F to 104°F (0°C to 40°C)
Storing:4°F to 167°F (-20°C to 75°C)
Humidity
80% maximum (non-condensing)
Dimensions
L = 2.95 inches (75mm)
W = 0.91 inches (23mm)
H = 0.7 inches (6.3mm)
Weight
0.021 lb (4.4g)
Certifications
FCC part 15b
Warranty
3 Year
* Compatible with USB 1.1 port. If used with 1.1 port, throughput may be diminished. ** Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely affect wireless signal range.
