Standards

• IEEE 802.11
• IEEE 802.11b
• Wi-Fi

Bus Type

32-bit PCI 2.2

Wireless Data Rates
With Automatic Fallback

• 22Mbps
• 11Mbps
• 5.5Mbps
• 2Mbps
• 1Mbps

Encryption

256-bit RC4

Media Access Control

CSMA/CA with ACK

Frequency Range

2.4GHz to 2.462GHz

Range

• Indoors: Up to 328 feet (100 meters)
• Outdoors: Up to 1,312 feet (400 meters)

Modulation Technology

• PBCC - Packet Binary Convolutional Coding
• Direct Sequence Spread Spectrum (DSSS)
• 11-chip Barker sequence

Modulation Techniques

• Barker (1Mbps/0db)
• Barker (2Mbps/3db)
• CCK (5.5Mbps/5.5db)
• PBCC (5.5Mbps/1.5db)
• CCK (11Mbps/8.5db)
• PBCC (11Mbps/4.5db)
• PBCC (22Mbps/8.5db)

Transmitter Output Power

15dBm (32mW) ± 2dB

External Antenna Type

Detachable / Reverse SMA

Over-Driving Levels

Tolerates up to +17dBm at the Antenna

Operating Temperature

32°F to 131°F ( 0°C to 55°C)

Humidity

95% maximum (non-condensing)

Dimensions

• L = 5.24 (133mm)
• W = 4.76 (121mm)
• H = 0.71 inches (18 mm)

Weight

0.17 lb (77g)
