OPIS PRODUKTU

General

Device Type

Router - 4-port switch (integrated)

Enclosure Type

Desktop

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet

Network / Transport Protocol

TCP/IP, PPTP, IPSec, PPPoE, PPPoA

Routing Protocol

RIP-2

Remote Management Protocol

SNMP, Telnet, HTTP

Encryption Algorithm

DES, Triple DES, IKE

Authentication Method

Secure Shell (SSH), PAP, CHAP

Features

Firewall protection, 56-bit encryption, auto-sensing per device, DHCP support, NAT support, PAT support, STAC-LZS compression, Syslog support, Stateful Packet Inspection (SPI), manageable

Processor

Motorola

RAM

64 MB (installed) / 80 MB (max)

Flash Memory

12 MB (installed) / 24 MB (max)

Status Indicators

Port status, power

Line Properties

Framing Format

ANSI T1.413

Communications

Type

DSL modem

Digital Signaling Protocol

ADSL

Protocols & Specifications

ITU G.992.2 (G.Lite), ITU G.992.3 (G.DMT.bis), ITU G.992.1 (G.DMT) Annex A

Expansion / Connectivity

Interfaces

Management : 1 x console - RJ-45 ¦ WAN : 1 x ADSL ¦ LAN : 4 x 10Base-T/100Base-TX - RJ-45

Power

Power Device

Power adapter - external

Voltage Required

AC 120/230 V ( 50/60 Hz )

Power Consumption Operational

10 Watt

Miscellaneous

Width

24.6 cm

Depth

21.6 cm

Height

5.1 cm

Weight

0.7 kg

Compliant Standards

EN 60950, IEC950, UL 1950, VCCI-II, EN55022 Class B, ICES-003 Class B

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 85%
