General
|
|
Device Type
|
Radio access point
|
|
Width
|
16.7 cm
|
|
Depth
|
18.4 cm
|
|
Height
|
4.2 cm
|
|
Weight
|
0.7 kg
|
|
Localisation
|
Europe
|
|
Processor / Memory / Storage
|
|
Processors Installed
|
1 x IBM PowerPC 405 200 MHz
|
|
Max Supported Qty
|
1
|
|
RAM Installed ( Max )
|
16 MB
|
|
Flash Memory Installed (Max)
|
8 MB Flash
|
|
Hard Drive
|
None.
|
|
Networking
|
|
Form Factor
|
External
|
|
Connectivity Technology
|
Wireless
|
|
Data Transfer Rate
|
54 Mbps
|
|
Line Coding Format
|
DBPSK, DQPSK, CCK, 64 QAM, BPSK, QPSK, 16 QAM
|
|
Data Link Protocol
|
IEEE 802.11b, IEEE 802.11g
|
|
Spread Spectrum Method
|
OFDM, DSSS
|
|
Remote Management Protocol
|
SNMP, Telnet, HTTP
|
|
Frequency Band
|
2.4 GHz
|
|
Selectable Channels Qty
|
13
|
|
Status Indicators
|
Status, alarm
|
|
Features
|
Auto-sensing per device, DHCP support, BOOTP support, ARP support, VLAN support, manageable
|
|
Encryption Algorithm
|
LEAP, AES, 128-bit WEP, 40-bit WEP, TLS, PEAP, TTLS, TKIP, WPA, WPA2
|
|
Authentication Method
|
RADIUS, Radio Service Set ID (SSID)
|
|
Compliant Standards
|
IEEE 802.3, IEEE 802.1p, IEEE 802.11b, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED
|
|
Expansion / Connectivity
|
|
Expansion Slot(s)
|
1 (total) / 0 (free) x mini PCI ¦ 1 (total) / 1 (free) x CardBus
|
|
Interfaces
|
1 x antenna - RP-TNC x 2 ¦ 1 x network - Ethernet 10Base-T/100Base-TX - RJ-45 ¦ 1 x management - console - RJ-45
|
|
Miscellaneous
|
|
Mounting Kit
|
Included
|
|
Compliant Standards
|
FCC Class B certified, ETSI, VCCI, EN 60950, ICES-003, UL 1950, IEC 60950, CSA 22.2 No. 950
|
|
|
