Cartridge Change:

10 seconds maximum

Indicators:

LCD menu display for drive, media, configuration, and diagnostic status; power, activity and alarm LEDs

Controls:

4-button keypad, recessed on-off switch on front panel

Interface:

High density, 68-pin, SCSI-2

Noise Level:

<58 dBA operation

Vibration:

.25g Sine (3-200 Hz) operating, tested per ISTA for storage/shipping

Shock:

31g operating, tested per ISTA for storage/shipping

Electrical:

100-240 V; 50-60 Hz; Auto Voltage Select

BTU/hr:

240

Humidity:

20 - 80% non-condensing operating

Altitude:

0 to 15,000 feet, at 25C ambient

Temperature:

50 to 95F (10 to 35C) operating

Hard Error Rate:

Less than 1 in 10¹⁷ bits read

Tape Shelf Life:

30 years minimum (at 20C, 40% RH)

Maintenance:

Head cleaning with cartridge when indicated by drive

MSBF:

Greater than 250,000 cartridge changes

MTBF:

Greater than 100,000 power-on hours (LTO and SDLT)

Dimensions (Rack Mount and Desktop)

Minimum

16.46"W x 24.34"D x 3.4"H
(41.8cm x 61.8cm x 8.5cm)

Maximum

16.62"W x 24.34"D x 3.5"H
(42.2cm x 61.8 cm x 8.7cm)

Rack Height:

2U (3.47"/8.8cm)

Weight:

20.94 lbs (9.5kg)

Shipping Weight:

27.56 lbs (12.5kg)

Safety:

IEC 60950 with worldwide country deviations, UL 1950 3rd edition, CSA950 C22.2

Emissions:

CISPR 22, EN5502 Class B

Immunity:

EN55024
